This warm isostatic press operates with high temperature and pressure, requiring strict adherence to thermal and pressure limits to prevent equipment damage. Proper hydraulic fluid selection and electrical grounding are essential for safe and reliable operation.

• Temperature and Pressure Limits: Do not exceed the maximum rated temperature of 300°C or pressure of 588.4 kN to avoid equipment failure.
• Hydraulic Fluid Compatibility: Use only approved liquid media such as clean water or special hydraulic oil to prevent seal degradation and system contamination.
• Electrical Requirements: Ensure the power supply matches the rated 2500W at 220V/110V and is equipped with proper grounding to mitigate electrical hazards.
• Safety Structure Engagement: Verify the flip-up safety lid is fully closed and secured before initiating any pressurization cycle.
• Operational Environment: Place the equipment on a stable, level surface in a well-ventilated area to maintain operational stability and reduce risk of overheating.

Initialize the press by inspecting the cavity and filling the hydraulic system with approved fluid. Program the desired temperature and pressure parameters on the touch screen, then perform a multi-stage pressurization cycle with continuous monitoring.

Required Equipment: Touch Screen Control Panel, Hydraulic System, Flip-up Safety Lid

1. Inspect Cavity
   Inspect the cavity and seals for cleanliness and integrity before each use.
2. Verify Hydraulic Fluid
   Verify the hydraulic fluid level and fill with approved clean water or special hydraulic oil as required.
3. Set Parameters
   Set the desired temperature and pressure parameters on the touch screen interface using custom process parameters.
4. Secure Safety Lid
   Close and secure the flip-up safety lid before initiating pressurization to ensure operator safety.
5. Start Pressurization
   Initiate the multi-stage pressurization cycle and monitor the pressurization map display for correct progression.
6. Release Pressure and Cool
   Release pressure slowly after completion and allow the cavity to cool before opening the safety lid and removing the sample.

This warm isostatic press offers precise temperature-pressure synergy and intelligent touch-screen operation for forming dense green bodies from powders, but its 3-liter cavity volume and 300°C maximum operating temperature limit throughput and restrict it to moderate-temperature, small-scale applications.

Positive

• Precise temperature-pressure synergy: Multi-stage pressurization with 0.98 kN display accuracy and ±2°C temperature control ensures uniform density and high forming compactness (>99.8%) for demanding powder materials.
• Intelligent touch-screen operation: A 7-inch touch screen enables fully automated process control, custom parameter setting, and production data export, reducing operator workload and improving reproducibility.

Trade-offs

• Limited cavity volume: The effective cavity volume is only 3 liters (Φ50×150 mm), which constrains sample size and batch throughput to small-scale R&D or pilot production.
• Moderate temperature ceiling: Maximum operating temperature is 300°C, characteristic of warm isostatic pressing; materials requiring higher sintering or hot isostatic pressing temperatures cannot be processed.
