ATOMFAIR® electrochemical capacity plot of NCM 622 cathode material research powder with 195 mAh per gram rating.

NCM 622 Cathode Material 195 mAh/g Research Powder ATOMFAIR®

Price range: $260.00 through $500.00

Institutional Procurement & Supply Compliance: As a verified US supplier, Atomfair accepts formal institutional Purchase Orders (POs), contract billing schedules, and custom procurement loops for university and national laboratories, and corporate R&D departments globally.

NCM 622 (60:10:30) research grade cathode powder, 195 mAh/g capacity, BET 0.871 m²/g, tap density 2.01 g/cm³, pellet density 3.04 g/cm³. Order now.

SKU: AF-BM-P-C622-195M-200G
Category:
Tags: ,
Brands:

Description

ATOMFAIR NCM (60:10:30): 195 mAh/g Cathode Active Material

RESEARCH GRADE MATERIAL

Product Overview
Engineered for advanced energy storage exploration, this premium medium-nickel single crystal cathode active material serves as a high-fidelity benchmarking matrix for state-of-the-art electrochemical cells. Synthesized with a highly stable 60:10:30 mono-crystal grain morphology, it leverages a hybrid layout that delivers highly optimized watt-hour economy alongside exceptional cycling retention metrics under elevated thermal testing conditions. Secure optimal institutional medium nickel mono crystal price points for scaled research and balanced energy development architectures.

Technical Specifications

PARAMETER DETAILS
1. Core Device & Electrochemical Design
Product Structural Configuration Medium Nickel Mono Crystal Type
Specific Surface Area (BET) 0.871 m²/g
Tap Density (TD) 2.01 g/cm³
Pellet Density (PD powder) 3.04 g/cm³
Surface Residual Alkali LiOH 0.0636 %wt
Surface Residual Alkali Li₂CO₃ 0.0729 %wt
pH Value 11.21
2. Cathode (Positive Electrode) Parameters
0.1C Charge Specific Capacity 217.6 mAh/g (CR2032 Coin Cell, 3.0V–4.4V)
0.1C Discharge Specific Capacity 195.2 mAh/g (CR2032 Coin Cell, 3.0V–4.4V)
Initial Coulombic Efficiency (Eff) 89.7 %
0.5C Discharge Capacity 184.1 mAh/g
1.0C Discharge Capacity 177.6 mAh/g
2.0C Discharge Capacity 171.0 mAh/g
Initial DCR (10% SOC @ 25°C) 14.37 Ω
Initial DCR (50% SOC @ 25°C) 40.63 Ω
Thermal DSC Peak Temp (4.40V) 245.2 °C (without electrolyte)
3. Anode (Negative Electrode) Parameters
Testing Counter Electrode Configuration Lithium Metal Target Half-Cell Foils / Pouch-cell vs. Graphite
4. Separator & Physical Package Metrics
Particle Size Distribution D0 / D100 0.408 μm / 9.244 μm
Particle Size Distribution D10 1.921 μm
Particle Size Distribution D50 3.810 μm
Particle Size Distribution D90 6.721 μm
Main Weight Component Profiles Ni: 36.02 %wt | Co: 6.01 %wt | Mn: 16.65 %wt | Li: 7.24 %wt
Transition Metal Molar Ratio (mol%) Ni: 60.24 mol% | Co: 10.01 mol% | Mn: 29.75 mol%
Trace Chemical Impurities profile S: 735 %wt
Manufacturing Rules Processed under strict RoHS compliant standard conditions
Alternative Options Explore our related catalog or custom dimensions. For urgent technical custom requests or bulk inquiries, please contact our support team.


Key Features & Advantages
  • Premium Watt-Hour Economy: Delivers an exceptionally high cost-performance index across the NCM6010 spectrum, providing uncompromised energy matrices at a reduced material processing threshold.
  • Excellent Thermal & Structural Safety: Features an optimized spinel-like robustness that guarantees an elite thermal decomposition profile at 245.2°C, effectively curbing microcracking during cyclic high-voltage charging fields.
  • Elite Pouch-Cell Cycling Benchmarks: Single-crystal structural design provides rugged resistance against degradation, registering 96.1% high-temperature capacity retention after 50 continuous runs at 45°C.

APPLICATION SCOPE: High-efficiency x-EV prototyping, medium-nickel layered crystal phase validation, volumetric energy density baselines, and cost-optimized battery cell testing.
PACKAGING: Sealed hermetically in premium protective container formats to isolate the single-crystal active cores from ambient contaminants.
IMPORTANT NOTICE: To preserve uncompromised surface purity and lattice phase validation integrity, store this medium-nickel formula under airtight anhydrous storage. Handle inside inert-gas glovebox platforms to eliminate gas cross-contamination or moisture degradation before validation testing workflows.

TAILORED SOLUTIONS FOR RESEARCH
Contact our engineering team for technical support or official institutional quotations.
EMAIL: inquiry@atomfair.com
Manufacturer: Atomfair LLC
Brand: ATOMFAIR®

This material contains surface residual alkali species that react with atmospheric moisture and carbon dioxide. Proper storage in a dry, inert atmosphere is required to maintain electrochemical performance.

  • Moisture and CO2 Sensitivity: Store under dry, inert atmosphere to prevent degradation from moisture and CO2 absorption.

How do the surface residual alkali levels in this NCM 622 cathode material impact its initial coulombic efficiency and electrode processing?

The surface residual alkali (LiOH 0.0636% wt and Li2CO3 0.0729% wt) are relatively low, enabling a high initial coulombic efficiency of 89.7% in CR2032 coin cells. Low residual alkali minimizes slurry gelation during NMP-based coating, allowing consistent electrode fabrication. Higher residual alkali would reduce efficiency and complicate processing, creating a trade-off between capacity and manufacturability.

Is this NCM 622 single crystal cathode material compatible with graphite anodes in full-cell pouch cell formats?

Yes, the material has been validated in pouch-cell configurations against graphite anodes, with initial DCR values of 14.37 Ω at 10% SOC and 40.63 Ω at 50% SOC, indicating acceptable impedance for full-cell operation. The single crystal morphology provides structural integrity to withstand volume changes during cycling, reducing electrode alignment issues.

What are the critical storage and safety considerations for this NCM 622 cathode powder?

The material's pH of 11.21 and residual alkali content (LiOH 0.0636% wt, Li2CO3 0.0729% wt) make it hygroscopic, requiring storage in airtight containers under low-humidity, inert atmosphere to prevent moisture-induced degradation. The DSC peak temperature of 245.2°C (without electrolyte) confirms high thermal stability under normal handling conditions, but storage in dry conditions is essential to maintain the 195 mAh/g discharge capacity.

This NCM 622 single-crystal cathode material delivers a 0.1C discharge capacity of 195.2 mAh/g with strong rate retention (177.6 mAh/g at 1C) and a DSC thermal onset of 245.2°C, indicating good stability for elevated-temperature evaluations. Its surface pH of 11.21 and initial DCR of 40.63 Ω at 50% SOC impose handling and impedance considerations for high-rate or moisture-sensitive deployments.

Positive

  • High specific capacity and rate capability: Delivers 195.2 mAh/g at 0.1C and retains 177.6 mAh/g at 1.0C (91% retention), enabling efficient energy delivery under moderate discharge currents.
  • Elevated thermal stability: DSC peak temperature of 245.2°C (without electrolyte) indicates robust structural stability, reducing thermal runaway risk during high-temperature operation or calorimetric screening.

Trade-offs

  • High alkalinity requires moisture control: pH of 11.21 combined with residual alkali (LiOH 0.0636%wt, Li₂CO₃ 0.0729%wt) necessitates dry-room or glovebox handling to prevent surface degradation and slurry gelation.
  • Moderate direct-current resistance at mid-SOC: Initial DCR of 40.63 Ω at 50% SOC (25°C) may limit power delivery and contribute to ohmic heating in high-rate or thick-electrode designs.

Every advanced material, component, equipment, and instrument in our catalog is backed by rigorous testing. We maintain strict internal quality management frameworks and align with CE conformity metrics to deliver transparent, reproducible performance data via our public open-science repository.

To request raw batch performance data, submit formal vendor registration paperwork, or execute a fast-turnaround R&D manufacturing loop, contact us at inquiry@atomfair.com.

Item is dispatched under the Atomfair Shipping & Delivery Framework (Free worldwide shipping on orders over $59 USD). Return is governed by the Atomfair Return & Refund Policy (7-day technical return window).

Additional information

Weight

200g, 1000g
