ATOMFAIR® ATOMFAIR-MTP6078 MANUAL TABLET PRESSRESEARCH GRADE MATERIAL
|
|||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||
|
TAILORED SOLUTIONS FOR RESEARCH
Contact our engineering team for technical support or official quotations.
EMAIL: inquiry@atomfair.com
|
|||||||||||||||||||||||||||||||
|
Manufacturer: Atomfair LLC
Brand: ATOMFAIR®
|
Store the press in a dry environment to prevent corrosion of steel components and degradation of hydraulic seals. Always verify the safety oil valve is set to the rated pressure limit before operation to avoid mechanical failure and injury.
- Hydraulic System Integrity: Inspect the hydraulic system for oil leaks and ensure the pressure gauge functions correctly before each use.
- Surface Maintenance: Clean the chromium steel and aluminum alloy surfaces with a dry cloth after each use to prevent moisture-induced pitting.
- Overload Protection: Do not exceed the maximum rated pressure indicated on the safety valve setting to prevent structural damage.
- Mold Storage: Store the tablet mold in a dry, padded container when not in use to maintain dimensional accuracy and prevent scoring.
- Operational Environment: Operate the press only on a stable, level surface away from flammable materials due to hydraulic oil content.
The Atomfair-MTP6078 manual tablet press is used to compress powder materials into uniform pellets under controlled hydraulic pressure. Follow these steps to safely prepare and operate the press for tableting.
Required Equipment: Atomfair-MTP6078 manual tablet press, Φ53mm tablet mold assembly
- Set Pressure Limit
Set the safety oil valve to the desired maximum pressure limit using the adjustment knob. - Assemble Mold
Place the appropriate mold assembly onto the lower platen and align the die cavity with the upper punch. - Load Sample
Transfer the powder sample into the die cavity ensuring even distribution and no spillage. - Compress
Pull the lever downward slowly to engage the hydraulic system and compress the powder to the target pressure. - Dwell
Hold the pressure for the required dwell time as specified in your protocol. - Eject Tablet
Release the lever to retract the piston and remove the compacted tablet from the die. - Clean
Clean the mold and platen surfaces with a lint-free cloth to remove residual material.
How does the manual operation of the Atomfair-MTP6078 affect tablet uniformity compared to automated presses, given its precision linear guide and fixed 30mm stroke?
The Atomfair-MTP6078 achieves uniform tableting through its precision linear guide and 30mm stroke, which ensure consistent compaction depth across the Φ53mm mold. The built-in pressure gauge enables real-time adjustment to maintain target force, while the safety oil valve prevents overpressure. Although manual operation introduces operator-dependent variability, these mechanical constraints and feedback systems provide sufficient repeatability for lab-scale battery material preparation.
Can the mold diameter be customized for pressing non-standard pellet sizes, and what constraints does the 30mm tablet stroke impose?
The standard Φ53mm mold is customizable on request, allowing adaptation to different pellet diameters. However, the tablet stroke is fixed at 30mm, limiting the maximum achievable tablet thickness regardless of mold size. The press's aluminum alloy and high-strength chromium steel construction maintains rigidity for custom molds, but compatibility of alternative diameters must be verified with the manufacturer to preserve precision guide alignment.
What safety features prevent overpressure damage during operation, and is any special training required to set the pressure limit?
The safety oil valve allows users to set an upper pressure limit, automatically preventing damage from excessive force due to operator error. The built-in pressure gauge provides continuous visual feedback of applied load. No special training is required for routine operation; initial calibration of the safety valve is straightforward using the gauge readout. The sturdy steel structure and environmentally friendly electroplating surface further enhance operational safety and durability.
The Atomfair-MTP6078 is a compact manual hydraulic press designed for lab-scale tableting, particularly for battery material powder compaction. Its labor-saving hydraulic structure and precise pressure control via an integrated gauge and safety valve offer reliable operation, though the 30mm stroke and 53mm mold constrain sample dimensions and throughput.
Positive
- Labor-saving hydraulic structure: The specially designed hydraulic mechanism reduces manual effort during compression, enabling easier operation compared to purely mechanical presses.
- Integrated pressure gauge and safety valve: The built-in pressure gauge provides real-time pressure monitoring, while the adjustable safety oil valve allows setting an upper pressure limit to prevent damage from overpressure.
Trade-offs
- Limited tablet stroke of 30mm: The maximum stroke of 30mm restricts the thickness of tablets or compacts that can be produced, which may not accommodate thicker samples or multi-layer pellets.
- Lab-scale design restricts throughput: The compact size and manual operation make the press suitable for small-scale laboratory work but inadequate for high-volume or continuous production environments.
