Atomfair Heat Sealing Machine Product Information
Model: Atomfair-HSM729
Launch Date: 2022-03-01
Dimensions: 320mm × 320mm × 500mm (L×W×H)
Weight: 30KG
Version: V2.0
Product Description
This heat sealing machine is mainly used for top and side sealing of flexible-packaged lithium-ion batteries. It works by generating heat through heating tubes and transferring it to the copper sealing head. Using heat conduction, the heat acts on the surface of the lithium battery aluminum-plastic film. Under specific pressure, the aluminum-plastic film is heated and softened to a near-molten state, thus completing the pressing and fusion bonding to achieve reliable sealing.
Features
-
The sealing head temperature can be precisely adjusted via a thermocouple and temperature controller, maintaining a constant temperature to ensure sealing consistency.
-
Equipped with a built-in pressure gauge for real-time monitoring and accurate control of sealing pressure, ensuring stable sealing quality.
-
Provides firm and tight sealing with flat, uniform sealing marks and a neat appearance, meeting product appearance requirements.
-
Adopts unique safety protection and anti-scald design to improve operational safety and prevent accidental burns.
-
Energy-saving efficiency is over 50% compared with similar products, effectively reducing operating costs.
-
Supports both top sealing and side sealing without mold replacement, improving operation efficiency and reducing mold replacement costs.
-
Easy to operate, safe and reliable, with an attractive, compact design that saves space.
Technical Parameters
|
Parameter Name
|
Specific Specifications
|
|---|---|
|
Sealing Head Length
|
≤200mm
|
|
Sealing Edge Width
|
Standard 5mm (Customizable as required)
|
|
Sealing Edge Thickness
|
0.15±0.3mm
|
|
Applicable Specifications
|
Side Sealing ≤200mm, Top Sealing ≤200mm (Including Air Bag), Customizable as required
|
|
Upper Mold Temperature
|
Max 300℃, Recommended 200℃
|
|
Lower Mold Temperature
|
Max 300℃, Recommended 100℃
|
|
Heat Sealing Pressure
|
0.5-0.7MPA, Adjustable
|
|
Sealing Time
|
Standard 2-3S (0-99S Adjustable)
|
|
Power Supply
|
AC220V/50Hz
|
|
Power
|
1000W
|
|
Overall Dimensions
|
320mm×320mm×500mm (L×W×H)
|
|
Equipment Weight
|
30KG
|
