ATOMFAIR® fine black vapor-grown carbon fibers VGCF powder inside a clear egg-shaped glass display bottle.

Vapor-Grown Carbon Fibers (VGCF) 100-200nm 50g ATOMFAIR®

$299.95

Institutional Procurement & Supply Compliance: As a verified US supplier, Atomfair accepts formal institutional Purchase Orders (POs), contract billing schedules, and custom procurement loops for university and national laboratories, and corporate R&D departments globally.

Research grade Vapor-Grown Carbon Fibers (VGCF) with 100-200 nm diameter and several μm length. For composites and conductive applications. Order now.

Quantity Price
1 – 4 $299.95
5 – 9 $189.95
10+ $139.95
SKU: AFINMVGCF100G
Category:
Tags:
Brands:

Description

ATOMFAIR® VAPOR-GROWN CARBON FIBERS (VGCF)

RESEARCH GRADE MATERIAL

Product Overview
Vapor-Grown Carbon Fibers (VGCF) are high-performance sub-micron filaments synthesized via an advanced vapor growth chemical configuration. Offering exceptional strength, structural flexibility, and electrical conductivity, this pristine matrix delivers elite baseline testing control and variable elimination for engineering units tracking competitive industrial carbon fiber price structures or configuring an uncompromised high performance applications conductive material framework.

Technical Specifications
PARAMETER DETAILS
1. Core Device & Nanoscale Morphology
Product Type Vapor-Grown Carbon Fibers (VGCF)
Fiber Diameter Typically ranges from 100 to 200 nm
Fiber Length Can exceed several micrometers (high aspect ratio layout)
2. Synthesis & Analytical Quality Trace
Synthesis Method Produced using catalytic chemical vapor deposition (CVD)
Characterization Techniques Scanning electron microscopy (SEM), transmission electron microscopy (TEM), and Raman spectroscopy
Manufacturing Rules Processed under strict [ISO 9001 standard compliance] parameters to safeguard reliable and reproducible testing baselines.
Alternative Options Explore our wide nanostructured carbon filament, single-walled, and multi-walled nanotube catalogs or request custom multi-kilogram batch allocations. For custom procurement metrics, contact our support interface.

Key Features & Advantages
  • Homogeneous Material Purity: Catalytic CVD configuration ensures uniform sub-micron fiber diameter distribution, delivering superior electrical conductivity.
  • Enhanced Operational Efficiency: High aspect ratio filaments provide exceptional mechanical reinforcement, significantly improving the overall strength and durability of composite materials.
  • Optimized Chemical Stability: Highly resistant to corrosion and chemical degradation in harsh environments while maintaining a lightweight form factor for mass-sensitive setups.

APPLICATION SCOPE: High-Performance Structural Composites (Plastics, Metals, Ceramics), Conductive Inks/Coatings, Supercapacitors, and Advanced Battery Technologies.
PACKAGING & STORAGE: Standard protective laboratory packaging. Store in a cool, dry place away from moisture and direct sunlight. Wear appropriate PPE during handling. Follow local chemical regulations for disposal.
IMPORTANT REMINDER: Sub-micron carbon filaments carry immense surface energy and naturally tend to cluster during processing. To completely resolve long-tail technical queries regarding how to prevent carbon fiber agglomeration, ensure uniform dispersion utilizing high-energy ultrasonication or specialized mechanical blending inside your specific carrier fluid setup prior to layer curing.

TAILORED SOLUTIONS FOR RESEARCH
Contact our engineering team for technical support or official institutional quotations. Use our high-quality materials to elevate your experimental performance!
EMAIL: support@atomfair.com
Manufacturer: Atomfair LLC
Brand: ATOMFAIR®

These carbon fibers are chemically stable but require protection from moisture to maintain electrical conductivity. Avoid exposure to high humidity environments and store in sealed containers.

  • Moisture Sensitivity: Store in a dry environment to prevent moisture absorption and preserve material properties.

How does the 100-200 nm diameter and several-micrometer length of Atomfair VGCF affect the electrical percolation threshold in polymer nanocomposites compared to standard carbon fibers?

The high aspect ratio (length exceeding several micrometers relative to 100-200 nm diameter) enables Atomfair VGCF to form a conductive network at significantly lower loadings than larger-diameter carbon fibers, reducing the percolation threshold. This trade-off allows simultaneous retention of mechanical properties and attainment of high electrical conductivity. The 'exceptional electrical conductivity' and 'high aspect ratio' features confirm the efficiency of these fibers for conductive nanocomposites.

What advantages and constraints does Atomfair VGCF offer as a conductive additive in lithium-ion battery electrode slurries?

Atomfair VGCF provide exceptional electrical conductivity for battery electrode formulations, as noted in the energy storage application scope. Their high aspect ratio, however, can increase slurry viscosity at lower concentrations, requiring adjustment of solvent content and dispersion methods. Specific loading levels are not predefined, so optimization through empirical testing is necessary to balance conductivity and processability.

What handling precautions are critical when working with Atomfair VGCF given their 100-200 nm diameter and potential for airborne fiber release?

The nanoscale diameter (100-200 nm) and micrometer-length fibers increase the risk of respirable particle generation. The product safety information mandates use of appropriate personal protective equipment (PPE) and storage in a cool, dry place away from sunlight and moisture. Users should additionally employ engineering controls like fume hoods and conduct a thorough risk assessment following local regulations for carbon material disposal.

Vapor-grown carbon fibers with diameters of 100–200 nm and lengths exceeding several micrometers provide high aspect ratio reinforcement and excellent electrical conductivity for composites and energy storage, but require controlled storage away from moisture and sunlight and mandatory respiratory protection during handling.

Positive

  • High Aspect Ratio Reinforcement: The fiber diameter of 100–200 nm and length exceeding several micrometers yield a high aspect ratio, enabling superior mechanical reinforcement in composite materials.
  • Exceptional Electrical Conductivity: VGCFs provide high electrical conductivity suitable for conductive inks, coatings, and energy storage devices including supercapacitors and batteries.

Trade-offs

  • Respiratory Protection Required: Nanoscale fiber diameters (100–200 nm) may generate respirable airborne particles, requiring appropriate PPE such as dust masks and gloves during handling to avoid inhalation risks.
  • Moisture and Light Sensitivity: The material must be stored in a cool, dry environment away from direct sunlight and moisture to maintain fiber integrity and prevent degradation or agglomeration.

Every advanced material, component, equipment, and instrument in our catalog is backed by rigorous testing. We maintain strict internal quality management frameworks and align with CE conformity metrics to deliver transparent, reproducible performance data via our public open-science repository.

To request raw batch performance data, submit formal vendor registration paperwork, or execute a fast-turnaround R&D manufacturing loop, contact us at inquiry@atomfair.com.
