ATOMFAIR® AH carbon nanotubes fine black powder inside a clear egg-shaped glass display bottle.

AH Carbon Nanotubes 75nm 100g >99.95% Purity ATOMFAIR®

$299.00

Institutional Procurement & Supply Compliance: As a verified US supplier, Atomfair accepts formal institutional Purchase Orders (POs), contract billing schedules, and custom procurement loops for university and national laboratories, and corporate R&D departments globally.

AH CNTs research grade: >99.95% purity, 75nm diameter, 6μm length, SSA 20-30 m²/g, ash <0.05%, magnetic foreign particles <1 ppm. Order now.

SKU: AFMSBUOF464
Category:
Brands:

Description

ATOMFAIR® AH CARBON NANOTUBES

RESEARCH GRADE MATERIAL

Product Overview
The ATOMFAIR® AH Carbon Nanotubes are engineered as a high-purity linear carbon matrix optimized to deliver excellent value relative to standard high-purity powder price metrics. Presenting in a premium straight-line physical configuration, this research-grade nanotube powder functions as an exceptional validation platform that establishes complete cell-to-cell consistency while successfully eliminating material processing variables. Designed explicitly as a high-efficiency matrix or solid state electrolyte material booster, it delivers specialized linear interface dynamics and excellent electrical conductivity to ensure absolute data reproducibility across high-end laboratory testing workflows.

Technical Specifications

PARAMETER DETAILS
1. Core Device & Electrochemical Design
Appearance Profile Pristine dry black powder form factor
Structural Morphology Straight-line linear carbon nanotube architecture
Elemental Purity >99.95% absolute high-purity track
Nanotube Diameter 75 nm precisely managed profile
2. Geometric & Conductive Performance Metrics
Nanotube Length 6 μm continuous physical network
Specific Surface Area 20-30 m²/g low footprint range (minimizes matrix binder consumption)
Tap Density Limit ≤0.2 g/cm³ optimized structural density parameters
Volume Resistivity <15 mΩ·cm under intensive 20MPa compaction metrics
Ash Content Limit <0.05% highly refined baseline index
Moisture Threshold <0.1% strict maximum limit control
3. Trace Element & Metal Purity Parameters
Total Metal Impurities <50 ppm overall background matrix (with Fe strictly managed <30 ppm)
Magnetic Foreign Matter <1 ppm to entirely eliminate parasitic electronic leakage
4. Manufacturing Rules & Alternatives
Manufacturing Rules Processed under strict ISO standard compliance conditions
Alternative Options Explore our specialized bent variations, single-wall nanotube arrays, or BH series benchmarks. Contact engineering for technical custom requests.

Key Features & Advantages
  • High-Purity Material Background: Highly refined carbon matrix exceeding >99.95% purity along with exceptionally low magnetic thresholds (<1 ppm) to guarantee uncompromised data reproducibility.
  • Straight-Line Morphology: Linear physical architecture optimized for standard matrix distribution, reducing cluster formations to build extended electronic transport networks.
  • Excellent Volumetric Conductivity: Delivers superior electronic transition kinetics, yielding a compressed volume resistivity profile of <15 mΩ·cm under 20MPa compaction.

APPLICATION SCOPE: High-performance battery conductive additives, composite network engineering, thermal management, and advanced electroanalytical development applications.
PACKAGING: Secure high-purity powder containment sealed hermetically to completely isolate dry particle characteristics from ambient environment variables.
IMPORTANT NOTICE: This material is processed to strict moisture bounds. Keep containers tightly closed and handle inside clean rooms or dry environments to avoid powder clusters, moisture absorption, or how to prevent moisture degradation bugs before final slurry validation workflows. Sold exclusively for laboratory research.

TAILORED SOLUTIONS FOR RESEARCH
Contact our engineering team for technical support or official institutional quotations.
EMAIL: inquiry@atomfair.com
Manufacturer: Atomfair LLC
Brand: ATOMFAIR®

This carbon nanotube powder must be stored in a dry, sealed container to prevent moisture absorption and maintain specified low moisture content. The fine particulate nature requires handling in a controlled environment to minimize aerosolization and potential inhalation exposure.

  • Moisture Control: Maintain low humidity environment to preserve the powder's specified moisture content below 0.1%.
  • Containment: Store in airtight, sealed containers to prevent moisture absorption and contamination from ambient air.
  • Handling Precautions: Use local exhaust ventilation or glovebox when transferring the powder to control airborne dispersion.

How does the straight-line morphology of AH Carbon Nanotubes influence their electrical percolation threshold in polymer composites compared to entangled or bundled CNTs?

The straight-line morphology of AH Carbon Nanotubes reduces percolation threshold by minimizing contact resistance along the tube axis. This is supported by a volume resistivity of <15 mΩ·cm at 20 MPa and a specific surface area of 20-30 m²/g, indicating more efficient electron transport pathways than typical entangled CNTs with higher interfacial junction resistance.

Can AH Carbon Nanotubes be used directly in high-precision electronic inks without post-synthesis purification given their stated metal impurity levels?

Yes, the as-received powder is suitable for high-precision electronic inks because total metal impurities are <50 ppm with Fe <30 ppm, and ash content is <0.05%. These values are well within typical tolerances for conductive ink formulations where metal contaminants could otherwise degrade electrical performance or cause short circuits.

What specific handling precautions are required for AH Carbon Nanotubes given their low tap density and potential for airborne dust generation?

Handling must be performed in a fume hood or glove box with HEPA filtration because the tap density is ≤0.2 g/cm³ and the powder has a 75 nm diameter, making it highly respirable and prone to aerosolization. Personal protective equipment including a NIOSH-approved N95 respirator, nitrile gloves, and lab coat is mandatory to prevent inhalation and skin contact.

This ATOMFAIR® AH Carbon Nanotube powder offers >99.95% purity and straight-line morphology with excellent conductivity (volume resistivity <15 mΩ·cm), making it suitable for high-performance conductive composites, but its low tap density (≤0.2 g/cm³) and fine powder form require careful handling and dispersion protocols.

Positive

  • Ultra-high purity and low metal residuals: Purity >99.95% with total metal impurities <50 ppm (Fe<30 ppm) minimizes catalytic interference and contamination in sensitive electronic and battery applications.
  • Outstanding electrical conductivity: Volume resistivity <15 mΩ·cm at 20 MPa enables efficient charge transport, ideal for conductive additives in electrodes and EMI shielding materials.

Trade-offs

  • Low tap density complicates handling: Tap density ≤0.2 g/cm³ means the powder is highly voluminous, requiring special attention to mixing, feeding, and compaction in composite processing.
  • Fine powder necessitates containment: As a black powder with low bulk density, the material is prone to airborne dispersion and must be handled with appropriate fume control and PPE to avoid inhalation and cross-contamination.

Every advanced material, component, equipment, and instrument in our catalog is backed by rigorous testing. We maintain strict internal quality management frameworks and align with CE conformity metrics to deliver transparent, reproducible performance data via our public open-science repository.

To request raw batch performance data, submit formal vendor registration paperwork, or execute a fast-turnaround R&D manufacturing loop, contact us at inquiry@atomfair.com.

Item is dispatched under the Atomfair Shipping & Delivery Framework (Free worldwide shipping on orders over $59 USD). Return is governed by the Atomfair Return & Refund Policy (7-day technical return window).
