Precision Constant Temperature Incubator, 1000 × 510 × 800 mm chamber with Programmable Control
Research-grade laboratory product
|
|||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||
|
LABORATORY PROCUREMENT SUPPORT
For model selection, accessory matching, installation-space review, power-supply confirmation or configuration support, contact our technical sales team.
E-MAIL: inquiry@atomfair.com
|
|||||||||||||||||||||||||||||||||||||||
|
Supplier: Atomfair
Brand: ATOMFAIR®
|
The incubator requires a controlled ambient environment between +5 and +35 °C and a compatible AC 220 V 50 Hz power supply. The unit must be kept upright during transport and positioned with accessible chamber, sensors, and controls for operation and maintenance.
- Ambient Temperature Range: The incubator must be operated within an ambient temperature range of +5 to +35 °C to maintain specified performance.
- Power Supply Requirements: The unit requires a dedicated AC 220 V 50 Hz power supply capable of delivering 1200 W rated power.
- Transport Orientation: During transport, the incubator must remain upright and be handled with suitable lifting equipment to prevent damage.
- Accessibility for Maintenance: The chamber, sensors, shelves, filters, doors, and control interfaces must remain accessible for routine cleaning, inspection, and operation.
- Over-Temperature Alarm Function: The independent over-temperature alarm system must be functional to ensure safe operation during unattended or extended use.
The following steps describe the safe installation and initial setup of the Precision Constant Temperature Incubator. The procedure covers positioning, power connection, controller programming, sample loading, and activation of safety features.
Required Equipment: Suitable lifting equipment, AC 220 V 50 Hz power supply
- Position the Incubator
Confirm that the installation site has a level floor, adequate space for the 1140 × 850 × 1080 mm external dimensions, and access to a dedicated AC 220 V 50 Hz power outlet. - Connect Power
Connect the incubator to the power supply and verify that the LCD controller powers on and displays the current chamber temperature. - Program the Controller
Set the desired temperature and program parameters using the multi-step programmable controller, then allow the chamber to stabilize at the set point. - Load Samples
Load samples onto the standard shelves, ensuring they do not obstruct the circulation fan intake, exhaust, or temperature sensors. - Activate Safety Features
Activate the independent over-temperature alarm and self-diagnosis functions before initiating unattended operation.
How does the automatic fan speed control on the Atomfair AF-PTIN-100 incubator affect temperature uniformity and sample protection?
The automatic circulation fan speed control adjusts to balance chamber uniformity and sample protection. The incubator achieves a temperature uniformity of ±1.5°C at 37°C, as stated in the technical specifications. This feature supports stable conditions for precision constant temperature experiments.
What power supply and ambient conditions are required for the Atomfair AF-PTIN-100 incubator?
The incubator requires an AC 220 V, 50 Hz power supply and a working ambient temperature range of +5 to +35°C. The external dimensions are 1140 × 850 × 1080 mm, so adequate space and ventilation must be provided. These specifications are directly listed in the product's technical specifications.
What safety and monitoring features does the Atomfair AF-PTIN-100 incubator include for unattended operation?
The incubator includes independent over-temperature alarm protection and self-diagnosis support displayed on the LCD screen for fault identification. An optional independent over-temperature controller is also available. During transport, reinforced packaging ensures the unit remains upright and protected.
The Precision Constant Temperature Incubator AF-PTIN-100 offers a 1000×510×800 mm chamber with programmable temperature control and fan speed management, delivering ±0.2°C fluctuation and ±1.5°C uniformity at 37°C for reproducible incubation workflows. Its stainless steel interior and rounded corners facilitate cleaning, but the 220V/50Hz power requirement and 5–35°C ambient operating range impose infrastructure constraints that must be verified before installation.
Positive
- Programmable temperature control: The LCD controller supports multi-step programmable operation, enabling complex, repeatable temperature profiles for precision incubation and cultivation workflows.
- Easy-clean stainless steel chamber: The 304-grade stainless steel inner chamber with rounded internal corners simplifies cleaning and decontamination, reducing cross-contamination risk between experiments.
Trade-offs
- 220V/50Hz power requirement: The unit requires a dedicated AC 220 V, 50 Hz supply; laboratories with 110 V or 60 Hz mains may need a step-up transformer or frequency converter, increasing installation complexity.
- Limited ambient temperature range: Specified working ambient temperature is +5 to +35 °C; operation outside this range may degrade temperature uniformity and control stability, necessitating a climate-controlled lab environment.
