Laboratory Pressure Sensor with Display ±0.1% FS ATOMFAIR®

This sensor requires careful handling to prevent damage from overpressure or chemical attack. Ensure proper electrical grounding and avoid exposure to temperatures outside the compensated range.

• Overpressure Protection: Limit applied pressure to the calibrated full scale (up to 10,000 psi) to avoid permanent sensor damage.
• Chemical Compatibility: Use only with media confirmed compatible with 316L stainless steel or Hastelloy wetted parts to prevent corrosion.
• Calibration Integrity: Recalibrate annually to maintain long-term stability below ±0.2% FS per year as per the NIST-traceable certificate.
• Thermal Management: Operate within the temperature compensation range (−20°C to +80°C) to avoid thermally induced measurement errors.
• Electrical Safety: Disconnect power before connecting output cables to prevent short circuits or damage to the interface electronics.

This procedure outlines safe installation and verification of the pressure sensor. Follow these steps to ensure accurate readings and prevent equipment damage.

Required Equipment: Pressure calibration standard, Wrench for fitting installation, USB or RS485 interface cable, Multimeter for output verification

1. Inspect the sensor
   Inspect the sensor housing, pressure port, and electrical connectors for visible damage or contamination.
2. Connect to system
   Connect the pressure port to the process line using the appropriate fittings and torque to the manufacturer’s specification.
3. Power and verify display
   Apply power to the sensor and confirm the digital display initializes with a baseline pressure reading.
4. Configure output
   Set the desired output protocol (USB, RS485, 0–10V, or Bluetooth) via the sensor’s software interface.
5. Reference check
   Apply a known reference pressure and verify the reading matches the calibration certificate within ±0.1% FS.
6. Record baseline
   Record the baseline pressure reading under ambient conditions for later comparison during experiments.
7. Monitor operation
   Monitor the sensor output continuously during the first operational cycle to confirm stable response.

This pressure sensor provides ±0.1% FS accuracy and a wide pressure range from 10 mTorr to 10,000 psi, suitable for vacuum systems and high-pressure reactors, but its -20°C to +80°C operating range and material selection requirements may limit deployment in extreme conditions.
