Titanium (Ti) Evaporation Material, Pieces, 99.9%, 3-6 mm
Product Type: Pure Metal Evaporation Material
Research-grade laboratory product
|
|||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||
|
LABORATORY PROCUREMENT SUPPORT
For material selection, deposition-source matching, pack-size confirmation or quotation support, contact our technical sales team.
INQUIRY: inquiry@atomfair.com
|
|||||||||||||||||||||||||||||||||||||||
|
Manufacturer: Atomfair LLC
Brand: ATOMFAIR®
|
Titanium (Ti) evaporation material requires water-cooled copper e-beam hearth with compatible liner materials (graphite, Al2O3, BN, or Ta). The material's melting point of 1,660°C, density of 4.5 g/cm³, and Z-ratio of 0.628 must be accounted for in deposition process parameters.
- Evaporation Source Compatibility: The material is compatible with water-cooled copper e-beam hearths and liners made of graphite, aluminum oxide, boron nitride, or tantalum.
- Evaporation Method: E-beam evaporation is the preferred deposition method for this titanium material.
- Process Parameter Constraints: The melting point of 1,660°C, density of 4.5 g/cm³, and Z-ratio of 0.628 must be incorporated into deposition process parameter calculations.
- Physical Form for Loading: The material is supplied as 3-6 mm pieces to facilitate source loading and consistent evaporation in e-beam systems.
Why is E-beam evaporation preferred for depositing titanium from this 99.9% pure material?
E-beam evaporation is preferred because titanium has a high melting point of 1,660°C and density of 4.5 g/cm³, requiring a high-energy source for controlled deposition. The material is compatible with water-cooled copper e-beam hearths and liners such as graphite, Al2O3, BN, or Ta, which prevent contamination and support stable evaporation rates.
What liner materials are compatible with titanium evaporation in e-beam systems?
Compatible liner materials for titanium evaporation include graphite, Al2O3, BN, and Ta. These are specified in the product details as compatible with the water-cooled copper e-beam hearth, selected to withstand the 1,660°C melting point of titanium and avoid chemical reactions during deposition.
What documentation and safety considerations should be reviewed before using titanium evaporation material?
Before use, buyers should review the certificate of analysis, safety data sheet (SDS), shipment conditions, and export requirements. The material is supplied as 3–6 mm pieces in pack sizes of 100g, 500g, or 1kg, and proper handling and storage conditions should be confirmed from the SDS to ensure laboratory safety and compliance.
This Titanium evaporation material (99.9%, 3-6 mm pieces) is suitable for e-beam deposition requiring high-purity Ti films, but its high melting point (1660°C) and Z-ratio (0.628) demand careful source matching and process calibration.
Positive
- High-purity titanium for thin-film deposition: 99.9% purity ensures consistent film properties and reduces contamination risks in vacuum deposition.
- Optimized piece size for e-beam evaporation: 3-6 mm pieces facilitate controlled feeding and uniform evaporation in water-cooled copper e-beam hearths.
Trade-offs
- High melting point requires robust source: Melting point of 1660°C necessitates high-power e-beam evaporation and compatible liner materials (graphite, Al2O3, BN, or Ta) to avoid hearth damage.
- Z-ratio of 0.628 requires calibration: The Z-ratio value demands accurate quartz crystal microbalance (QCM) calibration for reliable thickness monitoring during deposition.
