Programmable Climate Chamber 450 L, 0-50°C ATOMFAIR®

Programmable Artificial Climate Chamber, 450 L

Research-grade laboratory product

Product Overview

Programmable Artificial Climate Chamber, 450 L is a programmable LED light incubator or artificial climate chamber designed for plant growth, tissue culture, seed germination, insect culture, BOD work and climate-controlled biological cultivation. This configuration offers 450 l working volume, With lighting: 10 to 50 C; without lighting: 0 to 50 C, 50%rh to 90%rh humidity capability, 0 to 35000 lx, six-step adjustable lighting, mirror-finish stainless-steel chamber interior and programmable controller with multi-segment temperature, humidity, light and time setting for controlled laboratory operation.

This long-duration programmable family is positioned for cultivation programs that require stable running over weeks or months, using imported compressors, mirror-finish chamber construction and a circulation-air layout that limits direct draft on plants. The chamber uses two imported compressors with alternating long-duration operation design together with infrared CO2 sensor when the optional atmosphere-control package is selected, 3 shelves, helping the unit fit continuous cultivation, incubation, climate simulation or stability workflows where repeatable environmental control matters.

The family is designed for cultivation work that benefits from adjustable lighting levels, programmable climate changes and optional alarm, communication or CO2 functions without exposing pricing or source-notes in the public page. Installation planning can be based on the external size of 950 x 850 x 1850 mm with power requirement 2050 W. Optional functions such as rs485 or 232 communication interface and software; embedded printer; usb data storage; wireless alarm system; co2 inlet; infrared co2 controller; lighting control system allow the chamber to be configured for data logging, alarm notification, atmosphere support and application-specific monitoring.

Technical Specifications

Parameter	Specification / Available Values
Atomfair Model	AF-M2H0450
Capacity	450 L
Temperature Control Range	With lighting: 10 to 50 C; without lighting: 0 to 50 C
Temperature Resolution	0.1 C
Temperature Fluctuation / Uniformity	+/- 1 C
Humidity Function	50%RH to 90%RH
Humidity Deviation	+/- 5%RH to 7%RH
Lighting Configuration	0 to 35000 LX, six-step adjustable; LED three-side lighting; family lighting configurations range from top-mounted LED lighting to three-side and partition lighting systems
Controller	programmable controller with multi-segment temperature, humidity, light and time setting
Chamber Material	mirror-finish stainless-steel chamber interior
Power / Input	2050 W
Power Supply	AC 220 V, 50 Hz
Working Environment	+5 to 30 C
Sensor Configuration	infrared CO2 sensor when the optional atmosphere-control package is selected
Cooling System	two imported compressors with alternating long-duration operation design
Internal Dimensions	700 x 550 x 1140 mm
External Dimensions	950 x 850 x 1850 mm
Shelves / Light Decks	3 shelves
Program Function	30 program segments, each with time setting from 1 minute to 99 hours 59 minutes
Optional Accessories and Functions	RS485 or 232 communication interface and software; embedded printer; USB data storage; wireless alarm system; CO2 inlet; infrared CO2 controller; lighting control system

Performance Features

Long-duration running design uses imported compressors that automatically alternate to support continuous chamber operation. This supports dependable low-temperature performance and long-duration running stability.
Programmable control can set temperature, humidity, light intensity and time independently in multi-step processes. This helps improve environmental tracking for incubation, cultivation and stability-study workflows.
LED lighting is available in multiple chamber layouts, from top-mounted lighting to three-side or partition-style designs. This supports plant-growth or climate-chamber work that depends on repeatable illumination conditions.
Wireless alarm and fault-display functions help operators respond quickly when abnormal conditions appear. This helps protect samples and alert operators when abnormal conditions appear.
Optional CO2 inlet and infrared CO2 controller support specialized plant-growth workflows. This helps operators review setpoints, trends and alarms more efficiently during routine operation.
RS485 or 232 communication, USB export and printer options help create operation records and trend review. This supports more reliable day-to-day laboratory use in plant growth, tissue culture, seed germination, insect culture, BOD work and climate-controlled biological cultivation.

APPLICATION SCOPE: Suitable for plant growth, tissue culture, seed germination, insect culture, BOD work and climate-controlled biological cultivation in universities, research institutes, pharmaceutical quality-control laboratories, agricultural research programs and industrial test environments that require controlled chamber operation.

HANDLING: Confirm installation space against 950 x 850 x 1850 mm, prepare the stated power supply, and keep air inlets, exhaust paths, shelves, ports, doors and control interfaces accessible for cleaning and maintenance. Every unit is shipped with reinforced packaging to reduce movement and impact during transport; keep the packed chamber upright and use suitable lifting equipment.

IMPORTANT NOTICE: Select the required controller, lighting, humidity, communication and optional accessory configuration before ordering. Any displayed amount refers to the chamber body only and does not include freight. Freight is quoted separately and should be confirmed with shipping details.

LABORATORY PROCUREMENT SUPPORT

For model selection, accessory matching, installation-space review, power-supply confirmation or configuration support, contact our technical sales team.

E-MAIL: inquiry@atomfair.com

Supplier: Atomfair

Brand: ATOMFAIR®

How does the alternating compressor design in the Atomfair AF-M2H0450 climate chamber maintain temperature stability during long-duration cultivation runs?

The chamber uses two imported compressors that automatically alternate operation, which supports continuous long-duration running and dependable low-temperature performance. Temperature fluctuation and uniformity are specified at ±1°C across the 0–50°C (without lighting) or 10–50°C (with lighting) range, ensuring stable conditions for weeks-long cultivation programs.

Can the 450 L programmable climate chamber be configured for CO2-enriched plant growth studies, and what optional components are required?

Yes, the chamber supports CO2-enriched atmospheres when the optional atmosphere-control package is selected. This package includes an infrared CO2 sensor and a CO2 inlet; additionally, an infrared CO2 controller is available as a separate optional accessory. These components allow precise monitoring and control of CO2 levels for specialized plant growth workflows.

What infrastructure and space considerations are necessary for installing the AF-M2H0450 climate chamber in a laboratory?

Installation requires a space accommodating the external dimensions of 950 x 850 x 1850 mm, a dedicated AC 220 V, 50 Hz power supply with 2050 W capacity, and an ambient working environment of +5 to 30°C. Adequate clearance must be maintained for air inlets, exhaust paths, and access to shelves, ports, and control interfaces for cleaning and maintenance.

Assessment

The Atomfair AF-M2H0450 450L programmable artificial climate chamber provides controlled temperature (0-50°C with lighting), humidity (50-90% RH), and adjustable LED lighting (0-35000 lx) with a multi-segment programmable controller, making it suitable for long-duration plant growth and incubation studies. Its alternating compressor design supports continuous operation, but users must account for its 2050W power draw and humidity deviation of ±5-7% RH.

Positive

Alternating compressor long-duration design: Two imported compressors alternate automatically to support continuous, stable operation over weeks or months, reducing wear and improving reliability for long-term cultivation programs.
Multi-segment programmable control: The controller allows independent setting of temperature, humidity, light intensity, and time across up to 30 program segments, enabling precise environmental tracking for incubation, cultivation, and stability studies.

Trade-offs

Specific installation and power requirements: The chamber requires a 2050W, 220V/50Hz supply and a working environment of 5-30°C; external dimensions of 950x850x1850 mm demand adequate lab space and ventilation planning.
Humidity deviation tolerance: Specified humidity deviation of ±5% to 7% RH may limit applications requiring tight humidity control, such as certain seed germination or material stability protocols.
