Molybdenum (Mo) Evaporation Material, Pellets, 99.99%, 3-6 mm
Product Type: Pure Metal Evaporation Material
Research-grade laboratory product
|
|||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||
|
LABORATORY PROCUREMENT SUPPORT
For material selection, deposition-source matching, pack-size confirmation or quotation support, contact our technical sales team.
INQUIRY: inquiry@atomfair.com
|
|||||||||||||||||||||||||||||||||||||||
|
Manufacturer: Atomfair LLC
Brand: ATOMFAIR®
|
This product is a high-purity molybdenum pellet evaporation material for e-beam deposition. It requires specific evaporation source hardware and liner materials, and its process parameters must be matched to its melting point, density, and Z-ratio.
- Evaporation Source Compatibility: Must be used with water-cooled copper e-beam hearth and compatible liners including graphite, Al2O3, BN, or Ta.
- Process Parameter Matching: Melting point of 2,617°C and density of 10.2 g/cm³ require matching of evaporation source power and process route.
- Thickness Monitoring Calibration: Z-ratio of 0.257 must be entered into quartz crystal monitor for accurate film thickness deposition.
- Pre-Use Confirmation: Confirm model, purity, form, size range, pack size, and deposition-source compatibility before use.
- Documentation and Compliance Review: Review certificate, safety data sheet, shipment conditions, and export requirements against laboratory use requirements.
Why is E-beam evaporation preferred for these Mo pellets given their melting point?
E-beam evaporation is preferred because molybdenum has a high melting point of 2,617°C and a density of 10.2 g/cm³. The pellets are sized at 3–6 mm for optimal loading into water-cooled copper e-beam hearths with compatible liners such as graphite/Al₂O₃/BN/Ta.
Which liner materials are compatible with these Mo pellets during E-beam evaporation?
Compatible liner materials include graphite (graphite), Al₂O₃ (alumina), BN (boron nitride), and Ta (tantalum). These liners are suitable for use with water-cooled copper e-beam hearths when evaporating molybdenum at its melting point of 2,617°C.
What documentation should be reviewed before handling these Mo evaporation pellets in a laboratory?
Before handling these research-grade Mo pellets (99.99% purity), review the certificate of analysis for purity verification (99.99%), safety data sheet for handling precautions and storage conditions (e.g., dry environment), shipment conditions for moisture sensitivity considerations if applicable), and export requirements if needed.
Atomfair Molybdenum pellets (99.99% purity, 3-6 mm) are designed for e-beam evaporation with water-cooled copper hearth, offering defined pellet geometry for consistent deposition and compatibility with multiple liner materials (graphite, Al2O3, BN, Ta).
Positive
- Defined pellet size 3-6 mm: The specified 3-6 mm pellet size ensures consistent source loading and stable evaporation rate in e-beam systems, reducing run-to-run variability.
- Multiple liner material compatibility: Compatible with graphite, Al2O3, BN, and Ta liners, allowing flexible crucible selection based on thermal and chemical compatibility with the evaporation process.
Trade-offs
- E-beam evaporation preferred: The material is optimized for e-beam evaporation using a water-cooled copper hearth; thermal evaporation may require additional source considerations and liner compatibility verification.
- High melting point requires high power: With a melting point of 2,617°C, the material demands high-power e-beam sources and may induce thermal stress on liners, requiring careful process control.
