ZCL Series Nanocomposite Manganese Solid-State Cells (20Ah-40Ah High-Density) | ATOMFAIR
Product Overview
The ZCL Series represents the next frontier in solid-state battery technology, featuring an innovative nanocomposite manganese-based cathode paired with a high-rate graphite anode. Integrated with a proprietary electrolyte coating membrane, these cells achieve an industry-leading energy density of up to 200Wh/kg, enabling an ultra-long range of 120km+. Engineered for extreme reliability, the ZCL series maintains stable power output across a wide temperature spectrum (-30°C to 60°C) while reducing carbon emissions by 30% throughout its lifecycle. For bulk inquiries or official volume quotations, please contact us via email at inquiry@atomfair.com.
Technical Specifications
| Model Type | Cell Size (mm) | Nominal Capacity | Nominal Voltage | Energy Density | Operating Temp. | Cycle Life @RT |
|---|---|---|---|---|---|---|
| ZCL122175-20 | 9.5 * 122 * 175 | 20Ah | 3.7V | 191Wh/kg | -30°C to 55°C | ≥2000 Cycles |
| ZCL165227-40 | 10 * 165 * 227 | 40Ah | 3.7V | 197Wh/kg | -30°C to 55°C | ≥2000 Cycles |
| ZCL14894-30 | 26 * 148 * 94 | 30Ah | 3.7V | 170Wh/kg | -30°C to 55°C | ≥2000 Cycles |
Core Features & Advantages
Breakthrough Range
Achieves up to 200Wh/kg energy density, supporting an ultra-long range of over 120km for LEVs.
Extreme Cold Resistance
Stable output from -30°C to 60°C. Maintains >80% capacity retention at -20°C (1C discharge).
Eco-Friendly Innovation
Next-gen manganese technology enables a 30% reduction in carbon emissions throughout the product lifecycle.
Application Scope
- Small Power Systems (E-Bikes, Scooters)
- Professional High-Load Power Tools
- Robotics & Unmanned Systems
- Extreme Environment Power Solutions
Accessories & Customization
Technical Data: Full discharge curve data and thermal stability reports are available for research validation.
BMS Compatibility: Optimized for smart management systems supporting precise SOC/SOH monitoring at low temperatures.
Customization: Specialized cell dimensions and tab configurations are available for specific industrial prototyping.
How does the energy density vary across the 20Ah, 30Ah, and 40Ah ZCL series cells, and what impact does this have on range and low-temperature discharge performance?
The ZCL series cells offer three energy density levels: 191Wh/kg (20Ah), 197Wh/kg (40Ah), and 170Wh/kg (30Ah). The 40Ah cell achieves the highest density, enabling a manufacturer-rated ultra-long range of over 120km for light electric vehicles. All cells maintain stable output from -30°C to 60°C, with >80% capacity retention at -20°C under 1C discharge, regardless of variation.
What BMS compatibility considerations are critical for SOC/SOH monitoring with the ZCL series nanocomposite manganese solid-state cells in sub-zero conditions?
The ZCL series is optimized for smart BMS systems that support precise SOC and SOH monitoring at low temperatures. The cells operate from -30°C to 55°C, and the BMS must account for the voltage characteristics of the nanocomposite manganese cathode to maintain accuracy. Full discharge curve data and thermal stability reports are available from the manufacturer for research validation.
What specific performance characteristics make the ZCL series suitable for extreme environment power solutions?
The ZCL series maintains stable power output across an extreme temperature range of -30°C to 60°C, with >80% capacity retention at -20°C (1C discharge). The nanocomposite manganese cathode and proprietary electrolyte coating membrane deliver up to 200Wh/kg energy density and a cycle life of ≥2000 cycles at room temperature, making the cells viable for robotics, unmanned systems, and other extreme environment applications.
The ZCL Series nanocomposite manganese solid-state cells offer energy densities up to 200 Wh/kg with a wide -30°C to 60°C operating range, but energy density varies by capacity variant (170-197 Wh/kg) and low-temperature performance depends on compatible BMS integration.
Positive
- High Energy Density up to 200Wh/kg: The ZCL series achieves energy densities of 170-197 Wh/kg (up to 200 Wh/kg per model), enabling extended range for light electric vehicles and portable power systems.
- Wide Operating Temperature Range: These cells deliver stable output from -30°C to 60°C with >80% capacity retention at -20°C (1C discharge), making them suitable for extreme environment applications.
Trade-offs
- Non-Uniform Energy Density Across Variants: The three available models (20Ah, 30Ah, 40Ah) exhibit energy densities ranging from 170 to 197 Wh/kg, requiring careful selection based on specific capacity and energy requirements.
- BMS Dependency for Low-Temperature Performance: Full low-temperature capability requires an optimized smart BMS for precise SOC/SOH monitoring, adding system integration complexity for end users.
