Zirconium Oxide (ZrO2) Evaporation Material, Powder, 99.9%, 30 nm
Product Type: Compound Evaporation Material
Research-grade laboratory product
|
|||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||
|
LABORATORY PROCUREMENT SUPPORT
For material selection, deposition-source matching, pack-size confirmation or quotation support, contact our technical sales team.
INQUIRY: inquiry@atomfair.com
|
|||||||||||||||||||||||||||||||||||||||
|
Manufacturer: Atomfair LLC
Brand: ATOMFAIR®
|
Zirconium oxide powder for evaporation requires precise deposition source matching to avoid contamination and achieve uniform films. The material's high melting point and specific Z-ratio dictate the use of compatible hearth liners and boats for E-beam or thermal evaporation.
- Evaporation Method: E-beam evaporation is preferred; thermal evaporation requires RFQ to confirm compatibility with the material's melting point and behavior.
- Hearth and Boat Compatibility: Use an E-beam hearth with a graphite, Al2O3, or BN liner, or a W, Mo, or Ta boat for deposition.
- Material Properties for Deposition: The melting point of approximately 2700°C, density of 5.89 g/cm³, and Z-ratio of 1.00 are critical for matching deposition parameters.
- Process Matching: Match the evaporation source hardware and process route to the material's melting point and film requirements to ensure proper deposition.
Why is e-beam evaporation preferred over thermal evaporation for ZrO2 powder with 30 nm particle size?
E-beam evaporation is recommended because the product specification states 'E-beam evaporation preferred; thermal evaporation by RFQ' and rates e-beam performance as 'Good'. The material's high melting point (~2700°C) and powder form (30 nm) favor controlled e-beam heating in a graphite/Al2O3/BN liner or W/Mo/Ta boat to achieve consistent deposition rates.
What crucible or boat materials are compatible with ZrO2 evaporation to maintain purity?
Compatible evaporation source hardware includes an e-beam hearth with a graphite, Al2O3, or BN liner, or a W/Mo/Ta boat. The specification also lists graphite and tungsten as sheet hardware options. These materials are selected to withstand the ~2700°C melting point and minimize chemical reaction with ZrO2 during deposition.
What safety and documentation considerations apply when handling this 30 nm ZrO2 powder?
The product is research-grade and requires review of the certificate, safety data sheet (SDS), shipment conditions, and export requirements before use. The supplier explicitly advises confirming model, purity, form, size range, and deposition-source compatibility prior to quotation. Standard laboratory handling protocols for nanoscale powders should be followed.
This Zirconium Oxide (ZrO2) evaporation material in powder form with 30 nm particle size and 99.9% purity is evaluated for e-beam evaporation in thin-film deposition, offering good performance with specific liner and boat hardware requirements.
Positive
- High-purity 99.9% ZrO2 powder: The 99.9% purity specification enables consistent film stoichiometry and reduces contamination risks in optical or dielectric thin-film applications.
- Defined 30 nm particle size: The 30 nm powder form facilitates uniform source loading and controlled evaporation rates in e-beam hearths, supporting reproducible deposition processes.
Trade-offs
- High melting point constraint: With a melting point of approximately 2,700 °C, this material requires high-energy e-beam sources or specialized thermal evaporation setups, limiting compatibility with standard thermal boats without RFQ.
- Specific liner and boat requirements: Optimal e-beam performance necessitates graphite, Al2O3, or BN liners and W/Mo/Ta boats, adding procurement and setup complexity for labs without these components.
