Titanium (Ti) Evaporation Material, Pieces, 99.95%, 3-6 mm
Product Type: Pure Metal Evaporation Material
Research-grade laboratory product
|
|||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||
|
LABORATORY PROCUREMENT SUPPORT
For material selection, deposition-source matching, pack-size confirmation or quotation support, contact our technical sales team.
INQUIRY: inquiry@atomfair.com
|
|||||||||||||||||||||||||||||||||||||||
|
Manufacturer: Atomfair LLC
Brand: ATOMFAIR®
|
Titanium (Ti) evaporation material requires water-cooled copper e-beam hearth with a compatible liner such as graphite, Al₂O₃, BN, or Ta. The material's melting point of 1660°C, density of 4.5 g/cm³, and Z-ratio of 0.628 must be matched to the deposition process for controlled film deposition.
- Electron Beam Evaporation Requirement: Deposition must be performed using e-beam evaporation with a water-cooled copper hearth and a compatible liner to prevent contamination and ensure uniform heating.
- Melting Point Constraint: The material's melting point of 1660°C requires the evaporation source to achieve and maintain this temperature for controlled vaporization.
- Z-Ratio Integration: The Z-ratio of 0.628 must be used in the deposition controller to calibrate film thickness and rate monitoring.
- Density Consideration: The density of 4.5 g/cm³ affects the material's evaporation behavior and must be accounted for in process modeling.
Confirm the titanium material's purity, form, and size range match the deposition source requirements. Verify compatibility with the e-beam hearth liner and process parameters before loading the material into the vacuum chamber.
Required Equipment: Water-cooled copper e-beam hearth, Graphite, Al₂O₃, BN, or Ta liner, E-beam evaporation system, Deposition controller with Z-ratio setting
- Confirm Material Specifications
Confirm the titanium material's model, purity, form, and size range match the deposition source geometry. - Verify Hearth and Liner Compatibility
Verify the compatibility of the material with the water-cooled copper e-beam hearth and the liner material (graphite, Al₂O₃, BN, or Ta). - Program Deposition Controller Parameters
Program the deposition controller with the material's melting point of 1660°C, density of 4.5 g/cm³, and Z-ratio of 0.628 for process integration.
How does the Z-ratio of 0.628 for Titanium (Ti) evaporation material affect deposition rate monitoring in e-beam evaporation systems?
The Z-ratio of 0.628 is used to calibrate quartz crystal microbalance (QCM) sensors for accurate film thickness monitoring. A lower Z-ratio means the sensor's frequency change is more sensitive to mass deposition, requiring proper tooling factor adjustments. The product's specified Z-ratio of 0.628 is a standard value for titanium, allowing operators to input this parameter into deposition controllers for precise rate control.
Which crucible liner materials are recommended for e-beam evaporation of Titanium (Ti) pieces at 99.95% purity?
The manufacturer recommends using a water-cooled copper e-beam hearth with compatible liners including graphite, Al2O3 (alumina), BN (boron nitride), or Ta (tantalum). The choice of liner depends on the thermal and chemical compatibility with molten titanium at its melting point of 1,660°C. These liners prevent contamination and ensure stable evaporation rates.
What pack size and physical form considerations are important when ordering Titanium evaporation material for specific deposition runs?
The product is supplied as 3-6 mm pieces, ideal for loading into e-beam hearths without powder handling issues. Available pack sizes are 100g, 500g, and 1kg, with price tiers of $550, $1400, and $2000 respectively. Buyers should confirm their deposition source geometry and required quantity to select the appropriate pack size, ensuring adequate material for the run without excessive waste.
This 99.95% pure titanium evaporation material in 3-6 mm pieces is optimized for e-beam deposition, with defined particle size and purity to support consistent thin-film quality. Buyers must confirm deposition source geometry, liner compatibility, and pack size requirements before ordering to ensure operational fit.
Positive
- High purity (99.95%): The 99.95% purity specification minimizes contamination in deposited films, critical for achieving consistent electrical and optical properties in research thin-film applications.
- Optimized piece size (3-6 mm): The 3-6 mm piece size is tailored for e-beam evaporation sources, enabling uniform feeding and stable deposition rates while reducing the risk of source spitting or inconsistent layer formation.
Trade-offs
- E-beam evaporation only: This material is specified for e-beam evaporation with water-cooled copper hearths; other deposition methods (e.g., thermal evaporation) may not achieve adequate film quality or deposition efficiency.
- Pre-purchase compatibility check required: Buyers must verify deposition source geometry, liner material (graphite/Al2O3/BN/Ta), and crucible fit before ordering, as unverified configurations may lead to operational issues or material waste.
