Iron (Fe) Evaporation Material, Pellets, 99.99%, 1-3 mm
Product Type: Pure Metal Evaporation Material
Research-grade laboratory product
|
|||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||
|
LABORATORY PROCUREMENT SUPPORT
For material selection, deposition-source matching, pack-size confirmation or quotation support, contact our technical sales team.
INQUIRY: inquiry@atomfair.com
|
|||||||||||||||||||||||||||||||||||||||
|
Manufacturer: Atomfair LLC
Brand: ATOMFAIR®
|
This pure metal evaporation material requires careful matching of deposition source hardware and process parameters to achieve desired film properties. Prior to use, buyers must confirm deposition source geometry, pack size, and certificate requirements.
- Evaporation Source Compatibility: Use only with Mo/W/Ta boats, graphite/alumina crucibles, or e-beam hearths as specified for thermal or e-beam evaporation.
- Process Parameter Matching: Match evaporation source hardware and process route to the material's melting point of 1535°C, density of 7.86 g/cm³, and Z-ratio of 0.349.
- Deposition Source Geometry: Confirm that the deposition source geometry matches the pellet size and form factor before loading.
- Documentation Review: Review certificate of analysis, safety data sheet, and shipment conditions to ensure compatibility with laboratory use requirements.
- Pre-Order Confirmation: Confirm model, purity, form, size range, and pack size prior to submitting quotation request.
What evaporation source and crucible materials are compatible with Iron (Fe) pellets for thermal or e-beam deposition?
This Iron (Fe) evaporation material is compatible with Mo, W, or Ta boats for thermal/resistive evaporation, and with graphite or alumina crucibles for e-beam evaporation. The product specification explicitly lists these source materials as supported, ensuring direct integration into standard deposition hardware without additional compatibility testing.
How does the 99.99% purity and 1–3 mm pellet size of this iron evaporation material affect deposition uniformity and film quality?
The 99.99% purity minimizes contamination in deposited thin films, which is critical for reproducible electronic or magnetic properties. The 1–3 mm pellet size provides consistent source loading and controlled evaporation rates, reducing the risk of spitting or non-uniform flux during thermal or e-beam processes.
What are the key physical parameters—melting point, density, and Z-ratio—that influence process control when evaporating this iron material?
Iron has a melting point of 1,535 °C, a density of 7.86 g/cm³, and a Z-ratio of 0.349. These parameters are essential for setting e-beam power, monitoring film thickness via quartz crystal microbalance, and predicting material behavior during evaporation to achieve target film stoichiometry and thickness.
Iron (Fe) evaporation pellets with 99.99% purity and 1–3 mm size range are suited for thermal/resistive or e-beam deposition using Mo/W/Ta boats, graphite/alumina crucibles, or e-beam hearths. The defined material identity and pellet form enable clear procurement matching, but buyers must confirm deposition-source geometry, required quantity, and certificate requirements before quotation.
Positive
- High-purity defined material identity: 99.99% purity and clear Fe designation allow direct process matching for thin-film deposition without ambiguity in material specification.
- Multi-source evaporation compatibility: Pellets sized 1–3 mm are compatible with Mo/W/Ta boats, graphite/alumina crucibles, and e-beam hearths, supporting both thermal/resistive and e-beam evaporation methods.
Trade-offs
- Deposition-source geometry must be confirmed before order: Buyers must verify that the pellet size, source type, and crucible geometry match the deposition hardware; incompatibility can lead to loading issues or process failure.
- Procurement checks required before quotation: Model, purity, form, size range, pack size, and deposition-source compatibility must all be confirmed prior to ordering, adding an extra verification step for buyers.
