ATOMFAIR® 5-50 uL electronic pipette positioned in a digital control workflow layout for precise reagent aliquoting.

Electronic Single-Channel Pipette 5-50 μL ATOMFAIR®

$252.00

Institutional Procurement & Supply Compliance: As a verified US supplier, Atomfair accepts formal institutional Purchase Orders (POs), contract billing schedules, and custom procurement loops for university and national laboratories, and corporate R&D departments globally.

Single-channel electronic pipette with 5-50 μL range, 0.1 μL increment, ISO 8655-2 calibration reference, and lower-half autoclavable design. Order now.

SKU: AF-EI-L-DPPL-E050-SC00
Category: ,
Tags:
Brands:

Description

dPette+ Single-channel 5-50 µL Pipette

Product Type: Electronic pipette
Research-grade liquid handling platform

Product Overview

dPette+ Single-channel 5-50 µL Pipette is a fully autoclavable manual pipette for accurate microliter liquid handling in research, quality-control and teaching laboratories. The 5-50 µL range supports single-tube sample preparation, reagent addition, serial dilution, PCR or qPCR setup and routine analytical transfer where repeatability, stable tip fit and traceable calibration data are important.

Select this model according to its single-channel format, 5-50 µL working range, 0.1 µL increment, compatible tips and sterilization requirements. The technical specifications list the order model, product family, test volumes, systematic error, random error and calibration reference for procurement, method setup and routine performance review.

Key Features and Advantages
  • Single-channel configuration for single-tube sample preparation, reagent addition, serial dilution, PCR or qPCR setup and routine analytical transfer.
  • Volume range 5-50 µL with 0.1 µL increment.
  • Sterilization suitability: Lower half autoclavable.
  • Systematic error and random error values are listed by test volume for calibration review.
  • Suitable for routine liquid transfer, assay setup, sample preparation and laboratory training workflows.

Technical Specifications
Parameter Specification / Available Values
Atomfair Model AF-LH-DPETTE-PLUS-5-50-µL
Product Family dPette+
Channel count Single-channel
Volume range 5-50 µL
Increment 0.1 µL
Test volume(s) 50 / 25 / 5 µL
Systematic error At 50 µL: ±0.40 µL (±0.80%); at 25 µL: ±0.25 µL (±1.00%); at 5 µL: ±0.20 µL (±4.00%)
Random error At 50 µL: ±0.15 µL (±0.30%); at 25 µL: ±0.25 µL (±1.00%); at 5 µL: ±0.125 µL (±2.50%)
Sterilization suitability Lower half autoclavable
Calibration reference ISO 8655-2 user calibration reference indicated in the technical table
Technical table note Electronic pipette technical table
Configuration Support: Confirm compatible tips, calibration requirements, sterilization needs and laboratory workflow before ordering.
Technical Support: For method-specific volume matching, calibration planning, accessory compatibility or bulk laboratory configuration, contact the Atomfair technical sales team.
TAILORED SOLUTIONS FOR RESEARCH
For bulk orders, OEM requirements, accessory matching, platform selection or configuration confirmation, contact our engineering sales team.
EMAIL: inquiry@atomfair.com
Supplier: Atomfair
Brand: ATOMFAIR®

The pipette requires regular calibration per ISO 8655-2 to maintain specified accuracy. The lower half is autoclavable, but the upper electronic assembly must not be exposed to steam sterilization.

  • Sterilization Procedure: Autoclave only the lower half of the pipette at 121°C for 20 minutes; do not autoclave the upper assembly to prevent damage to electronic components.
  • Calibration Requirements: Perform calibration at the three test volumes (50 µL, 25 µL, 5 µL) using the specified systematic and random error limits as acceptance criteria.
  • Tip Compatibility: Use only tips that provide a secure, airtight fit to prevent leakage, ensure volume accuracy, and maintain stable tip fit.
  • Error Verification: Verify systematic and random errors at least annually or after any impact, disassembly, or recalibration to ensure continued performance.

How does the accuracy of the dPette+ 5-50 µL pipette change when operating at the lower end of its volume range compared to the upper end?

Accuracy degrades significantly at the lower end of the range. At 50 µL, the systematic error is ±0.40 µL (±0.80%) and random error is ±0.15 µL (±0.30%). At 5 µL, systematic error is ±0.20 µL (±4.00%) and random error is ±0.125 µL (±2.50%), representing a five-fold increase in relative systematic error and an eight-fold increase in relative random error compared to the 50 µL test volume.

What calibration standard does the dPette+ 5-50 µL pipette reference, and how does it support method validation in regulated laboratories?

The pipette references ISO 8655-2, the international standard for piston-operated volumetric apparatus. The technical specifications provide systematic and random error values at three test volumes (50, 25, and 5 µL), enabling users to perform user calibration checks directly against the standard, which is essential for method validation and compliance in regulated laboratory environments.

What are the sterilization limitations for the dPette+ 5-50 µL pipette, and why is partial autoclaving recommended?

Only the lower half of the pipette is autoclavable; the upper half containing electronic components must not be autoclaved. This partial sterilization is specified to prevent heat and moisture damage to the electronic assembly while allowing decontamination of the tip-holding and volume-adjustment mechanism that comes into contact with samples.

The dPette+ Single-channel 5-50 µL pipette offers a research-grade liquid handling platform with a 0.1 µL increment and autoclavable lower half, but systematic error increases significantly at the 5 µL test volume (4.00%), and user calibration per ISO 8655-2 is required for traceability.

Positive

  • Single-channel precision pipetting: Single-channel configuration enables accurate single-tube sample preparation, reagent addition, serial dilution, and PCR setup with a 0.1 µL increment.
  • Lower half autoclavable: The lower half of the pipette is autoclavable, allowing sterilization for contamination-sensitive workflows without requiring full unit autoclaving.

Trade-offs

  • Systematic error rises at low volume: At 5 µL, systematic error is ±4.00% (±0.20 µL), which is considerably higher than at 50 µL (±0.80%), limiting accuracy for very small volume transfers.
  • User calibration per ISO 8655-2 required: Calibration reference is provided per ISO 8655-2, meaning users must perform routine calibration verification to maintain stated performance, adding procedural overhead.
