3.95V 260Wh/kg Semi-Solid Battery 43Ah Series | ATOMFAIRCOMMERCIAL GRADE · PRODUCTION
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
TAILORED SOLUTIONS FOR RESEARCH
Contact our engineering team for technical support or official institutional quotations.
EMAIL: inquiry@atomfair.com
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Manufacturer: Atomfair LLC
Brand: ATOMFAIR®
|
This document establishes the mandatory environmental storage and operational safety constraints for the ATOMFAIR semi-solid battery series. Adherence to these constraints is necessary to prevent thermal runaway, leakage, or capacity degradation.
- BMS Protection Requirement: Always use a compatible battery management system (BMS) with over-discharge, over-current, and cell balancing protection.
- Voltage Range Compliance: Charge the battery only within the manufacturer's recommended voltage range to avoid overcharge or undercharge damage.
- Temperature Exposure Limit: Avoid exposing the cells to excessive temperatures for extended periods to prevent thermal stress and degradation.
- Pre-conditioning Requirement: Pre-condition new cells at a suitable temperature before first use to stabilize the semi-solid electrolyte.
- Peak Discharge Duration Limit: Do not exceed the rated peak discharge duration (10C) to prevent overheating and irreversible damage.
These steps describe the safe handling, pre-conditioning, charging, and discharging procedures for the ATOMFAIR semi-solid battery series. Proper execution of these steps ensures safe operation and maximizes cycle life.
Required Equipment: Compatible battery management system (BMS) with over-discharge, over-current, and cell balancing protection, Constant current / constant voltage (CC/CV) charger capable of 2C charge rate, Multimeter for voltage verification
- Inspect cell condition
Inspect the pouch cell for physical damage, swelling, or leakage before initiating any electrical connection. - Connect BMS
Connect the battery to a compatible BMS, ensuring correct polarity and secure electrical contacts. - Pre-condition cell
Pre-condition the cell at the recommended temperature for at least one hour before the first charge cycle. - Charge battery
Charge the battery at a constant current of 2C until the nominal voltage is reached, then switch to constant voltage until current tapers. - Discharge normally
Discharge the battery at a continuous rate of up to 5C for normal operation, and do not exceed the 10C peak rate beyond the rated duration. - Store safely
Store the battery in a moisture-barrier vacuum-sealed bag in a cool, dry environment when not in use.
How does the semi-solid electrolyte in the ATOMFAIR 43Ah battery improve thermal stability and safety compared to conventional liquid electrolyte cells?
The semi-solid electrolyte reduces leakage risk and improves thermal stability, as stated in the product features. The battery delivers 260Wh/kg energy density with 2C charge, 5C continuous discharge, and 10C peak discharge, demonstrating that the semi-solid design supports high rate capability without compromising safety. The pouch cell format also enhances thermal management.
What BMS specifications are necessary for integrating the ATOMFAIR 43Ah semi-solid battery into a high-drain UAV or robotics system?
A compatible BMS must provide over-discharge, over-current, and cell balancing protection, as explicitly required in the product notice. The battery operates at 3.95V nominal cell voltage with series configurations from 6S to 18S, so the BMS must be matched to the specific pack voltage (e.g., 23.7V for 6S). Additionally, charge within the manufacturer's recommended voltage range and do not exceed the rated peak discharge duration.
What are the recommended storage and pre-conditioning procedures for the ATOMFAIR 43Ah semi-solid battery before first use?
The battery ships in moisture-barrier vacuum-sealed aluminum foil bags and must be stored in anti-static cartons. Before first use, pre-condition new cells at a suitable temperature as advised in the product notice. Avoid exposing cells to excessive temperatures for extended periods. Dispose of cells in accordance with local regulations.
The ATOMFAIR 3.95V 260Wh/kg Semi-Solid Battery 43Ah Series offers a semi-solid electrolyte design that enhances safety and thermal stability while delivering 260 Wh/kg energy density and 5C continuous discharge capability, making it suitable for high-rate UAV and robotics applications. The four voltage configurations (6S to 18S) provide flexibility for different system voltages, but the pouch cell format and required BMS integration impose handling and infrastructure constraints.
Positive
- High energy density 260 Wh/kg: The 260 Wh/kg energy density enables extended runtime in lightweight designs, critical for UAVs and portable devices where mass and volume are constrained.
- Semi-solid electrolyte safety: The semi-solid electrolyte reduces leakage risk and improves thermal stability compared to liquid electrolytes, enhancing operational safety in high-rate discharge scenarios.
Trade-offs
- Requires compatible BMS: The battery must be used with a BMS providing over-discharge, over-current, and cell balancing protection; failure to integrate a suitable BMS risks cell damage or unsafe operation.
- Pouch cell handling sensitivity: Pouch cells are mechanically sensitive to puncture and swelling; the moisture-barrier vacuum-sealed packaging must be maintained, and cells require careful handling to avoid physical damage during installation or transport.
