Conductivity Electrode 0-200 μS/cm Glass BNC ATOMFAIR®

Conductivity Electrode 0-200 μS/cm Glass BNC ATOMFAIR®

$103.00

Institutional Procurement & Supply Compliance: As a verified US supplier, Atomfair accepts formal institutional Purchase Orders (POs), contract billing schedules, and custom procurement loops for university and national laboratories, and corporate R&D departments globally.

Research-grade glass-body conductivity electrode for routine aqueous solutions, 0–200 μS/cm range, 12 mm × 125 mm probe, BNC interface. Order now.

SKU: AF-EI-E-ELEC-COND-RNL5
Category:
Tags: , , ,
Brands:

Description

IoniProbe Conductivity 0.1 CG Conductivity electrode

Product Type: Electrochemistry Electrode
Research-grade laboratory product

Product Overview

Electrochemistry Electrode IoniProbe Conductivity 0.1 CG Conductivity electrode supports Conductivity electrode with 0-200 uS/cm and Diameter 12 mm x 125 mm in a Glass body.

It is configured for electrochemistry meter workflows where electrode model, measurement medium, connector, reference solution and application fit must be checked before purchase.

Application: Routine aqueous solution. Interface: BNC.

Performance Features
  • Electrode or accessory type: Conductivity electrode.
  • Measurement range: 0-200 uS/cm.
  • Temperature compensation: 10K where listed in the product configuration; otherwise not included.
  • Interface: BNC.
  • Electrode body: Glass.
  • Reference solution: Not applicable.
  • Application fit: Routine aqueous solution.

Technical Specifications
Parameter Specification / Available Values
Atomfair Model AF-IONPCONDUCTIVITY01CG
Electrode model IoniProbe Conductivity 0.1 CG
Name Conductivity electrode
Electrode body Glass
Cable length 1 m unless specified otherwise
Internal temperature compensation 10K where listed in the product configuration; otherwise not included
Interface BNC
Reference solution Not applicable
Specification Diameter 12 mm x 125 mm
Measurement range 0-200 uS/cm
Application Routine aqueous solution

Selection and Use Notes
  • Confirm electrode model, connector, body material, cable length, reference solution and sample medium compatibility before quotation.
PROCUREMENT CHECK: Confirm model, working range, compatibility, consumables and required configuration before quotation.
DOCUMENTATION REVIEW: Product specifications and configuration details are reviewed against laboratory use requirements.
ACCESSORY MATCHING: Compatible accessories, replacement parts and consumables can be matched according to the selected configuration.
RFQ NOTE: Include the required model, configuration and quantity when requesting quotation support.
LABORATORY PROCUREMENT SUPPORT
For model selection, accessory matching, platform compatibility or configuration confirmation, contact our technical sales team.
E-MAIL: inquiry@atomfair.com
Manufacturer: Atomfair LLC
Brand: ATOMFAIR®

This conductivity electrode is designed for measurement in routine aqueous solutions within a range of 0-200 µS/cm. Compatibility with the meter's BNC input and the presence of temperature compensation must be verified before use.

  • Connector Compatibility: The electrode uses a BNC connector and must be paired with a meter that has a matching BNC input.
  • Measurement Range: The electrode is rated for conductivity measurements from 0 to 200 µS/cm; samples outside this range are not suitable.
  • Application Medium: The electrode is intended for routine aqueous solutions only and should not be used in non-aqueous or organic solvents.
  • Temperature Compensation: Temperature compensation is provided via a 10K sensor only when explicitly configured in the product; otherwise, compensation is not included.
  • Reference Solution: This conductivity electrode does not require a reference solution for operation.

Does the IoniProbe Conductivity 0.1 CG electrode include automatic temperature compensation, and how does its absence affect accuracy for samples at non-standard temperatures?

The electrode does not include internal temperature compensation unless the product configuration explicitly lists a 10K compensation option. Without it, users must manually correct readings for temperature effects, which can introduce significant error for samples outside 25 °C since conductivity is temperature-dependent.

Can this 0.1 cell constant glass-body conductivity electrode be used with meters requiring a 4-pin connector or a built-in temperature sensor?

No, this electrode uses a standard BNC interface for the conductivity cell only and does not include a separate temperature sensor or 4-pin connector. It is intended for electrochemistry meters with a single BNC input; compatibility with the meter's input type must be verified before purchase.

What are the critical handling and storage requirements for the glass-body IoniProbe Conductivity 0.1 CG electrode to prevent damage and maintain calibration stability?

The glass body is fragile and requires careful handling to avoid breakage. After use, rinse the electrode with deionized water and store it in a clean, dry environment or per the manufacturer's recommended storage protocol. Avoid mechanical shock, organic solvents, and non-aqueous samples, as the electrode is designed only for routine aqueous solutions.

The IoniProbe Conductivity 0.1 CG electrode is a glass-bodied conductivity sensor designed for low-conductivity routine aqueous solutions (0–200 µS/cm) with a BNC interface, eliminating the need for a reference solution but requiring confirmation of temperature compensation inclusion before purchase.

Positive

  • No reference solution required: The electrode configuration specifies no reference solution, simplifying setup and maintenance for routine aqueous measurements.
  • Routine aqueous solution compatibility: Explicitly optimized for routine aqueous solutions, ensuring reliable performance in common laboratory conductivity applications.

Trade-offs

  • Limited to low conductivity range: Measurement range of 0–200 µS/cm restricts use to low-conductivity samples only; not suitable for mid- or high-conductivity solutions.
  • Temperature compensation conditional: Internal 10K temperature compensation is only present if explicitly listed in the product configuration; otherwise absent, requiring external compensation or strict temperature control.
