Description
IoniProbe Conductivity 201 T Conductivity electrodeProduct Type: Electrochemistry Electrode
Research-grade laboratory product
|
|||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||
|
LABORATORY PROCUREMENT SUPPORT
For model selection, accessory matching, platform compatibility or configuration confirmation, contact our technical sales team.
E-MAIL: inquiry@atomfair.com
|
|||||||||||||||||||||||||||||||||
|
Manufacturer: Atomfair LLC
Brand: ATOMFAIR®
|
This electrode is specified for routine aqueous solution applications only. Compatibility of the connector, body material, cable length, and reference solution must be confirmed with the meter and sample medium before use.
- Connector and Interface Compatibility: Verify that the 4-core interface connector matches the meter's input and that the cable length (default 1 m) is appropriate for the setup.
- Application Medium: Use only with routine aqueous solutions; non-aqueous, viscous, or extreme pH media are not validated.
- Temperature Compensation: If internal temperature compensation (10K) is not configured, manual temperature compensation must be applied during measurements.
- Measurement Range: Ensure the sample conductivity falls within the 0-200.0 mS/cm range to avoid sensor damage or inaccurate readings.
How does the wide measurement range of 0–200.0 mS/cm affect accuracy for low-conductivity samples with the IoniProbe Conductivity 201 T electrode?
The electrode covers a very broad range up to 200.0 mS/cm, which is suited for routine aqueous solutions but may compromise resolution at the low end (e.g., below 1 μS/cm) because the full range is scaled for high-conductivity measurements. The product description specifies an application of “Routine aqueous solution” and does not list dedicated low-conductivity features, so ultrapure or low-ionic-strength samples may require a different electrode design for acceptable precision.
What connector and temperature compensation configuration are required to integrate the IoniProbe Conductivity 201 T electrode with a conductivity meter?
The electrode uses a 4-core interface, so the meter must have a matching 4-core input for both conductivity measurement and, if needed, temperature compensation. Automatic temperature compensation is only active when the product configuration explicitly includes a 10K thermistor; otherwise, no internal compensation is provided. Verify the selected configuration and meter compatibility before purchase.
What sample medium limitations and handling precautions apply to the plastic-body IoniProbe Conductivity 201 T electrode?
The electrode is intended exclusively for routine aqueous solutions; the plastic body may be less resistant to strong oxidizers, organic solvents, or highly acidic/alkaline media compared to glass-bodied alternatives. Physical dimensions are 12 mm diameter × 120 mm length with a 1 m cable, so it fits standard electrode holders but requires sufficient immersion depth for accurate measurement. No reference solution is required, but the electrode should be rinsed with deionized water after use to avoid cross-contamination.
The IoniProbe Conductivity 201 T electrode offers a wide measurement range (0–200.0 mS/cm) and a plastic body suitable for routine aqueous solution conductivity measurements, but requires explicit configuration for temperature compensation and has a fixed 1 m cable length that may limit laboratory placement flexibility.
Positive
- Wide conductivity measurement range: The electrode measures 0–200.0 mS/cm, covering a broad spectrum of routine aqueous solution conductivity applications.
- Plastic body for routine use: The plastic electrode body provides chemical resistance suitable for common aqueous laboratory environments.
Trade-offs
- Inconsistent temperature compensation: Temperature compensation at 10K is only included when explicitly configured; otherwise absent, requiring manual correction or compensation from the meter.
- Cable length constraints: Standard cable length is 1 m unless specified otherwise, which may limit placement flexibility in some laboratory setups.
