Description
IoniProbe Conductivity 201 TG Conductivity electrodeProduct Type: Electrochemistry Electrode
Research-grade laboratory product
|
|||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||
|
LABORATORY PROCUREMENT SUPPORT
For model selection, accessory matching, platform compatibility or configuration confirmation, contact our technical sales team.
E-MAIL: inquiry@atomfair.com
|
|||||||||||||||||||||||||||||||||
|
Manufacturer: Atomfair LLC
Brand: ATOMFAIR®
|
This conductivity electrode is designed for pure water solution measurements with a 0-200.0 mS/cm range. Compatibility with the meter's 4-core interface and proper selection of temperature compensation are required for accurate operation.
- Connector Compatibility: The electrode uses a 4-core interface and must be matched with a meter that supports this connector type.
- Application Medium Constraint: The electrode is specified for pure water solutions; use with other media may require verification of compatibility.
- Temperature Compensation: Temperature compensation of 10K is only active if configured in the product option; otherwise, measurements are not temperature-compensated.
Does the IoniProbe Conductivity 201 TG electrode include automatic temperature compensation for conductivity measurements?
The IoniProbe Conductivity 201 TG includes internal temperature compensation (10K) only when specifically listed in the product configuration; otherwise it is not included. Users must verify whether their selected configuration specifies temperature compensation, as this directly affects measurement accuracy in environments with fluctuating temperatures.
Can the IoniProbe Conductivity 201 TG electrode be used for conductivity measurements in water samples other than pure water, such as tap water or industrial process water?
The IoniProbe Conductivity 201 TG is specifically intended for pure water solution applications as stated in the product description. Its glass body and 4-core interface are optimized for low-ionic-strength matrices, and using it with high-conductivity or chemically aggressive samples may compromise accuracy or damage the electrode.
What are the physical dimensions, cable length, and connector requirements for integrating the IoniProbe Conductivity 201 TG into a standard electrochemistry meter?
The electrode has a diameter of 12 mm and length of 125 mm, with a standard 1 m cable (other lengths may be specified). It uses a 4-core interface, so the meter must have a matching 4-core input. The glass body requires careful handling to avoid breakage, and no reference solution is needed.
The IoniProbe Conductivity 201 TG is a glass-body conductivity electrode designed for pure water analysis, offering a broad measurement range up to 200.0 mS/cm. Its 4-core interface requires confirmation of temperature compensation inclusion before deployment.
Positive
- Wide conductivity measurement range: The electrode supports 0–200.0 mS/cm, enabling measurements from low to highly conductive pure water solutions without requiring a different sensor.
- Glass body for minimal contamination: The glass electrode body is chemically inert and well-suited for pure water applications, reducing leaching risks and maintaining sample integrity.
Trade-offs
- Conditional temperature compensation: Internal 10K temperature compensation is included only when explicitly listed in the product configuration; otherwise it is absent, requiring users to verify before purchase.
- Application restricted to pure water: The electrode is optimized for pure water solutions; compatibility with other sample types must be confirmed prior to use, as specified in the selection notes.
