65 Ah Square-Shell Sodium-Ion Power Cell

65 Ah Square-Shell Sodium-Ion Power Cell

$129.00

Institutional Procurement & Supply Compliance: As a verified US supplier, Atomfair accepts formal institutional Purchase Orders (POs), contract billing schedules, and custom procurement loops for university and national laboratories, and corporate R&D departments globally.

65 Ah Square-Shell Sodium-Ion Power Cell for sodium-ion battery applications. Confirm the selected configuration, quantity and integration requirements before quotation.

SKU: AF-BT-S-P065-6500-0004
Category:
Brands:

65 Ah Square-Shell Sodium-Ion Power Cell | ATOMFAIR

Product Type: Sodium-ion battery product
Sodium-ion battery product

Product Overview

The 65 Ah square-shell sodium-ion power cell is specified for high-power battery systems with a 3.10 V nominal voltage, 4C continuous charging and 6C continuous discharging.

The cell combines a 175 x 27 x 204 mm class format with a 20-80% recommended SOC range and at least 10,000 cycles under the listed cycle test.

Performance Features
  • 65 Ah rated capacity and 3.10 V nominal voltage.
  • 4C continuous charging and 6C continuous discharging.
  • 10C pulse charging and 12C pulse discharging for 10 seconds.
  • Operating temperature range of -40 to 55 C.
  • At least 80% capacity retention after 10,000 cycles under the listed cycle test.

Technical Specifications
Parameter Specification / Available Values
Atomfair Model AF-SQ-65A
Product Form Aluminum square-shell sodium-ion power cell
Rated Capacity 65 Ah
Nominal Voltage 3.10 V
Operating Voltage 2.0-4.0 V at or above 0 C; 1.5-4.0 V below 0 C
Dimensions 175 +/-1 x 27 +/-1 x 204 +/-1 mm; pole center distance 123 +/-0.3 mm
Weight 1.77 +/-0.15 kg
Continuous Charge / Discharge 4C / 6C
Pulse Charge / Discharge 10C / 12C for 10 seconds
Cycle Life >=80% after 10,000 cycles under 20-80% SOC and 3C charge / 3C discharge
Safety GB 38031-2020 pass listed in the specification
Before Quotation: Confirm the selected 65 Ah square-shell cell model, quantity and intended vehicle or storage application before quotation.
Specification Confirmation: Review capacity, voltage window, current rate, low-temperature capacity and cycle-life requirements against the planned pack design.
Application Matching: Match dimensions, pole spacing, cooling strategy and BMS limits with the downstream module or pack.
Information to Include: Include target capacity, voltage, C-rate, quantity, operating temperature and assembly constraints.
