2kW SOFC Fuel Cell Stack AF-FC-2K 50-Cell ATOMFAIR®

$6,296.00

Institutional Procurement & Supply Compliance: As a verified US supplier, Atomfair accepts formal institutional Purchase Orders (POs), contract billing schedules, and custom procurement loops for university and national laboratories, and corporate R&D departments globally.

Research-grade 2kW SOFC fuel cell stack with 50 cells, 100 mm × 100 mm cells, 150 × 150 × 150 mm dimensions, hydrogen or natural gas fuel, 750°C operation. Order now.

2 kW SOFC Fuel Cell Stack | ATOMFAIR

Product Type: Fuel cell stack

Research-grade hydrogen energy product

Product Overview

2kW fuel cell stack with 50-cell configuration, 100 mm x 100 mm single-cell size, and 150 x 150 x 150 mm.

The stack supports hydrogen, natural gas as the fuel gas and is shown with a 750°C test point. Performance points at multiple cell voltages are listed below for quotation confirmation.

Performance Features

Rated output: 2kW.
Cell count: 50.
Single-cell size: 100 mm x 100 mm.
Fuel gas: Hydrogen, natural gas.
Multiple thermal cycling.

Technical Specifications

Parameter	Specification / Available Values
Atomfair Model	AF-FC-2K
Rated Power	2kW
Cell Count	50
Single-Cell Size	100 mm x 100 mm
Dimensions / Footprint	150 x 150 x 150 mm
Fuel Gas	Hydrogen, natural gas
Thermal Cycling	Multiple thermal cycling
Test Temperature	750°C

Cell Voltage	Stack Voltage	Current	Power
0.75 V/cell	36.00 V	56.00 A	2016.00 W
0.80 V/cell	38.40 V	49.00 A	1882.00 W
0.85 V/cell	40.80 V	39.00 A	1591.00 W

MODEL CONFIRMATION: Confirm the 2kW configuration, cell count, footprint, and fuel gas before quotation.

CONFIGURATION FIT: Match the selected stack to the target hydrogen energy platform and installation envelope.

QUOTATION DETAILS: Include the selected model, quantity, and power rating when requesting quotation support.

LABORATORY PROCUREMENT SUPPORT

For model selection, platform compatibility or configuration confirmation, contact our technical sales team.

E-MAIL: inquiry@atomfair.com

Supplier: Atomfair

Brand: ATOMFAIR®

Constraints

The 2 kW SOFC fuel cell stack requires a test temperature of 750°C and is compatible only with hydrogen or natural gas fuel. The stack supports multiple thermal cycling but specific cycle limits are not provided.

Operating Temperature: The stack must be operated at 750°C to achieve the specified power output.
Fuel Gas Compatibility: Only hydrogen or natural gas are approved as fuel gases for this stack.
Thermal Cycling: The stack is rated for multiple thermal cycles, but no maximum cycle count is specified.
Rated Power: The stack should not be operated beyond its rated power of 2 kW.
Installation Envelope: The stack dimensions of 150 x 150 x 150 mm constrain the installation space.

FAQ

What power output can I expect from the 2 kW SOFC stack at different operating cell voltages?

At 0.75 V/cell, the stack delivers 2016 W (36.00 V, 56.00 A). At 0.80 V/cell, output is 1882 W (38.40 V, 49.00 A). At 0.85 V/cell, output is 1591 W (40.80 V, 39.00 A). The rated output is 2 kW.

Which fuel gases are supported by the Atomfair 2 kW SOFC stack and at what test temperature?

The stack supports hydrogen and natural gas as fuel gases. It is tested at a 750°C operating point and supports multiple thermal cycling.

What are the physical dimensions and cell configuration of the 2 kW SOFC stack?

The stack measures 150 x 150 x 150 mm and contains 50 cells, each with a single-cell size of 100 mm x 100 mm.

Assessment

The AF-FC-2K 2 kW SOFC stack uses a 50-cell, 100 x 100 mm planar architecture in a 150 x 150 x 150 mm footprint and is specified for hydrogen or natural gas operation at a 750°C test point. Measured output spans 1591 W at 0.85 V/cell to 2016 W at 0.75 V/cell, with multiple thermal cycling capability documented.

Positive

Dual-fuel SOFC flexibility: The stack accepts both hydrogen and natural gas as fuel gas, giving platform integrators fuel-sourcing flexibility without changing the 50-cell stack configuration.
Defined performance operating points: Measured output is provided at 0.75, 0.80, and 0.85 V/cell, allowing system designers to select a voltage/current operating point based on power delivery and stack voltage requirements.
Multiple thermal cycling capability: The stack is specified for multiple thermal cycling, supporting repeated heating and cooling in research and test deployment scenarios.

Trade-offs

High-temperature operating requirement: The stack is shown with a 750°C test point, so laboratory integration must include high-temperature thermal management, insulation, and heat-up infrastructure.
Power output varies with cell voltage: Delivered power changes from 2016 W at 0.75 V/cell to 1591 W at 0.85 V/cell, meaning the rated 2 kW level is only reached at the lower-voltage operating point and must be confirmed for the intended load.
