200W SOFC Fuel Cell Stack | ATOMFAIRProduct Type: Fuel cell stack
Research-grade hydrogen energy product
|
|||||||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||||||
|
LABORATORY PROCUREMENT SUPPORT
For model selection, platform compatibility or configuration confirmation, contact our technical sales team.
E-MAIL: inquiry@atomfair.com
|
|||||||||||||||||||||||||||||||||||||||||||
|
Supplier: Atomfair
Brand: ATOMFAIR®
|
What is the maximum power output of the ATOMFAIR AF-FC-200W SOFC stack at 0.60 V/cell, and how does it compare to the rated 200W specification?
At 0.60 V/cell, the stack delivers a peak measured output of 283.06 W (78.41 A, 3.61 V stack voltage), exceeding the rated 200W specification. The 200W rating is based on a more conservative operating point at 0.70 V/cell (204.00 W), representing the design point for sustained performance. This difference allows engineers to trade off between higher power density and cell voltage efficiency depending on application demands.
Can the AF-FC-200W SOFC stack operate on natural gas as fuel in addition to hydrogen, and what infrastructure constraints apply?
Yes, the stack supports both hydrogen and natural gas as fuel gas, as explicitly stated in the performance features and technical specifications. Operation with natural gas implies the need for upstream fuel processing or internal reforming capability, although the source does not detail specific reformer integration requirements. The test point of 750°C indicates the operating temperature window for SOFC electrochemical conversion, which must be maintained regardless of fuel choice.
What are the physical envelope constraints for integrating the AF-FC-200W stack into a hydrogen energy platform?
The stack footprint is 150 mm x 150 mm with a customizable height that includes piping, as noted in the specifications under dimensions and footprint. The single-cell size is 100 mm x 100 mm with a 6-cell configuration. The height is explicitly customizable to accommodate installation envelope requirements, making it suitable for integration where vertical space is a critical constraint. Researchers must verify that the 150 mm square base aligns with their gas manifold layout and thermal enclosure design.
This 200W SOFC stack with a 6-cell configuration and 100 mm x 100 mm single-cell size operates at 750°C, supporting hydrogen and natural gas fuels with multiple thermal cycling capability, delivering up to 283 W at 0.60 V/cell.
Positive
- Dual fuel flexibility: Accepts both hydrogen and natural gas as fuel gas, enabling operational versatility across different hydrogen energy platforms without stack replacement.
- Multiple thermal cycling tolerance: Designed for multiple thermal cycling, reducing mechanical stress during repeated start-up and shut-down sequences typical in research and testbed deployments.
Trade-offs
- High operating temperature requirement: Tested at 750°C, necessitating high-temperature-rated piping, insulation, and thermal management infrastructure that increases system complexity and energy input for heating.
- Customizable height adds integration risk: Height includes piping and is customizable, requiring careful envelope matching and potential re-engineering of mounting or enclosure interfaces during procurement.
