Tungsten Evaporation Boat, Step Type, Flat Tub, 0.2 x 15 x 100 mm
Product Type: Evaporation Boat
Research-grade laboratory product
|
||||||||||||||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||||||||||||
|
LABORATORY PROCUREMENT SUPPORT
For model selection, accessory matching, platform compatibility or configuration confirmation, contact our technical sales team.
E-MAIL: inquiry@atomfair.com
|
||||||||||||||||||||||||||||||||||||||||||||
|
Manufacturer: Atomfair LLC
Brand: ATOMFAIR®
|
This evaporation boat must be used in a vacuum environment and matched to the source holder geometry. Electrical ratings must be verified against the power supply, and the maximum operating temperature must not exceed 1200°C.
- Vacuum Environment: Operate the boat only within a vacuum chamber to prevent oxidation and ensure proper resistive heating.
- Geometry Compatibility: Confirm that the boat overall dimensions, tub geometry, and tub capacity match the evaporation source holder before installation.
- Electrical Matching: Verify that the power supply voltage (1.47 V), current (204 A), and power (300 W) ratings match the boat specifications.
- Temperature Limit: Do not exceed the maximum rated temperature of 1200°C during operation to avoid material degradation.
Follow these steps to install the evaporation boat in a vacuum deposition system. Ensure all electrical and mechanical connections are secure before applying power.
Required Equipment: Vacuum deposition system, Resistive heating power supply, Evaporation source holder
- Inspect Boat
Inspect the boat for physical damage, deformation, or contamination before installation. - Mount Boat
Mount the boat securely into the evaporation source holder, ensuring proper alignment of the tub with the source material. - Connect Power Supply
Connect the power supply leads to the boat terminals, verifying correct polarity and tight connections. - Verify Electrical Ratings
Verify that the power supply voltage, current, and power settings match the boat's rated values of 1.47 V, 204 A, and 300 W. - Evacuate Chamber
Evacuate the vacuum chamber to the required base pressure before applying power to the boat. - Apply Power Gradually
Apply power gradually to heat the boat to the desired evaporation temperature, not exceeding 1200°C. - Monitor Temperature
Monitor the boat temperature continuously during operation to prevent exceeding the maximum limit.
What electrical specifications must be matched to operate this tungsten evaporation boat at its maximum rated temperature of 1200 °C?
The boat requires 1.47 V, 204 A, and 300 W. These values must be confirmed against the available resistive-heating power supply before ordering, as the electrical rating is a configuration value for power-supply review. The maximum temperature of 1200 °C is supported only when the power supply matches these specifications.
Which dimensions and geometry features are critical for ensuring the tungsten evaporation boat fits the evaporation source holder?
Critical dimensions include thickness (0.2 mm), width (15 mm), length (100 mm), tub length (40 mm), tub depth (2.3 mm), and tub capacity (0.8 cc). The boat has a step-type geometry with a flat tub and down step 5.7. These parameters must be matched to the source holder and mating components to ensure proper installation and compatibility.
What is the minimum order quantity and what package options are available for this tungsten evaporation boat?
The minimum order quantity is 5 pieces. Package options include 1 pack of 5 pcs or 1 pack of 10 pcs, as specified in the product variations. These options are available for quotation planning and procurement.
Tungsten evaporation boat with step-type flat tub geometry, 0.2x15x100 mm overall dimensions, 0.8 cc tub capacity, and 1200 °C maximum temperature rating, designed for vacuum evaporation source loading with resistive heating.
Positive
- Tungsten Construction for High-Temperature Stability: Tungsten construction provides high melting point and thermal stability for resistive-heating evaporation processes up to 1200 °C.
- Defined Geometry for Precise Fit: Specified overall dimensions (0.2x15x100 mm) and tub geometry (40 mm length, 2.3 mm depth, 0.8 cc capacity) enable dimensional matching with evaporation source holders.
Trade-offs
- Requires Compatibility Verification: Boat material, overall dimensions, tub geometry, and capacity must be confirmed against the evaporation source holder before installation to ensure proper fit.
- Power Supply Matching Required: Voltage (1.47 V), current (204 A), and power (300 W) ratings must be matched with the resistive-heating power supply to avoid operational mismatch.
