ATOMFAIR® LMR-D02 LITHIUM-RICH MANGANESE-BASED CATHODE (LMR) ELECTRODE SHEET

RESEARCH GRADE MATERIAL

Product Overview

Atomfair LMR-D02 is a premium Lithium-rich Manganese-based Cathode (LMR) electrode sheet, double-side coated with 54.6 mg/cm² via an advanced dry process. Engineered specifically for next-generation Lithium-ion battery R&D, this material ensures cell-to-cell consistency, baseline testing control, variable elimination, and electrolyte validation platform benefits while nesting target lithium-rich manganese-based cathode lmr electrode sheet price structures to optimize laboratory validation integrity.

Technical Specifications

PARAMETER	DETAILS
1. Core Device & Electrochemical Design
Product Code	D02
Capacity	300 mAh/g
Coating Process	Dry Process
2. Cathode Parameters
Coating Material	LMR (Lithium-rich Manganese-based Cathode)
Active Material Ratio	96.00%
Coating Density	54.6 mg/cm²
Coating Area	90 × 120 mm
Coating Type	Double-sided
Compaction Density	2.6 g/cm³
3. Substrate & Foil Parameters
Substrate Material	Carbon-coated aluminum foil matrix crystals
Current Collector Density	4.2 mg/cm²
Substrate Thickness	12 + 0.5 + 0.5 μm
Substrate Size	90 × 140 mm
4. Compliance & Support
Pack Size	5 sheets/pack
Manufacturing Rules	Processed under strict ISO 9001 compliance conditions
Alternative Options	Explore our related catalog or custom dimensions. For urgent technical custom requests or bulk inquiries, please contact our support team.

Key Features & Advantages

Homogeneous Material Purity: Formulated with a 96.00% active material matrix to secure maximum active targets concentration and robust kinetics across half-cell foils benchmarking setups.
Enhanced Operational Efficiency: Features a carbon-modified interlayer over the premium foil collector to minimize interfacial contact resistance, reduce contact polarization, and extend test cell cycling metrics.
Advanced Dry Process Technology: Advanced dry processing ensures robust mechanical binder structures, coordinating a flawless double-sided film uniformity at 54.6 mg/cm² loading across the 90 × 120 mm area without local solvent variations.
Tailored Solutions: Full customization architecture comprehensively supports flexible geometric modifications for coating thickness, localized breadth, and aluminum substrate specifications.

APPLICATION SCOPE: High-capacity Lithium-ion battery R&D, structural material validation, localized benchmarking, and advanced electrochemical performance analysis.

PACKAGING: 5 electrode sheets per pack (Substrate size: 90 × 140 mm), packaged tightly to safeguard strict laboratory batch constants and preserve uniform material quality parameters during baseline diagnostics.

IMPORTANT NOTICE: This product is sold exclusively for laboratory research. Recommended baking protocol: Process and maintain strictly for 12 hours under vacuum at 100°C to prevent moisture contamination or structural degradation before high-stakes thermal validation testing workflows.

TAILORED SOLUTIONS FOR RESEARCH

Contact our engineering team for technical support or official institutional quotations.

EMAIL: inquiry@atomfair.com

Manufacturer: ATOMFAIR LLC

Brand: ATOMFAIR®

Disclaimer: Sold exclusively for laboratory research.

This electrode sheet is moisture-sensitive and must be vacuum-dried before use to prevent structural degradation. The manufacturer prescribes a 12-hour vacuum bake at 100°C for all laboratory evaluations.

Vacuum Drying Protocol: A 12-hour vacuum drying step at 100°C is required before thermal validation testing.
Moisture Contamination Risk: Moisture contamination can cause structural degradation of the electrode coating.
Research Use Restriction: This product is sold exclusively for laboratory research and should not be used in clinical or commercial applications.

HowTo

This procedure describes the required vacuum drying of LMR-D02 cathode sheets before use. Following these steps prevents moisture-induced structural degradation during thermal validation.

Required Equipment: Vacuum oven

Load sheets
Transfer the cathode sheets into a vacuum oven capable of reaching 100°C.
Set temperature
Set the vacuum oven temperature to 100°C.
Apply vacuum
Evacuate the oven chamber and maintain the vacuum continuously.
Bake for 12 hours
Maintain the oven at 100°C under vacuum for 12 hours.
Cool and remove
Cool the oven to ambient temperature before removing the dried sheets.

FAQ

How does the carbon-modified interlayer on the current collector improve the electrochemical performance of the LMR-D02 electrode sheet?

The carbon-modified interlayer on the carbon-coated aluminum foil current collector minimizes interfacial contact resistance and reduces contact polarization. This design improves electrical contact stability, which helps extend test cell cycling metrics. The electrode sheet features a 96.00% active material ratio and a high loading of 54.6 mg/cm², enabling high capacity (300 mAh/g) while maintaining structural integrity.

What substrate thickness and coating dimensions are specified for the LMR-D02 electrode, and how do they affect standard laboratory cell assembly?

The substrate is a carbon-coated aluminum foil with a total thickness of 12 μm core plus 0.5 μm coating on each side (12+0.5+0.5 μm). The double-side coating covers a 90×120 mm area on a 90×140 mm substrate. These dimensions are designed for consistent electrode punching for coin cells or pouch cells, ensuring reproducible active material loading and cell-to-cell consistency in research.

What is the recommended drying protocol for the LMR-D02 electrode sheet before high-stakes thermal validation testing?

The manufacturer recommends baking the electrode sheets under vacuum at 100°C for 12 hours to prevent moisture contamination and structural degradation. This protocol is essential because the lithium-rich manganese-based cathode material is moisture-sensitive, and improper drying can compromise electrochemical performance. The product is sold exclusively for laboratory research and must be handled according to these guidelines.

Assessment

This LMR-D02 electrode sheet combines a 96% active material matrix with double-side dry coating at 54.6 mg/cm², delivering 300 mAh/g capacity for high-energy lithium-ion R&D, but mandates a 12-hour vacuum bake at 100°C to prevent moisture-induced degradation and is restricted to laboratory use only.

Positive

96% active material matrix: The high active material ratio (96.00%) maximizes electroactive concentration, supporting robust kinetics and consistent half-cell benchmarking.
Carbon-modified interlayer reduces contact resistance: The carbon-coated aluminum foil substrate minimizes interfacial contact resistance and contact polarization, which can extend test cell cycling metrics.

Trade-offs

Mandatory vacuum baking protocol: To prevent moisture contamination and structural degradation, the electrode sheets must be processed under vacuum at 100°C for 12 hours before thermal validation workflows.
Laboratory research use only: This product is sold exclusively for laboratory research, not for production or commercial battery manufacturing, limiting applicability to pilot or industrial scale.
