ATOMFAIR® NFPP-S03 SODIUM IRON PHOSPHATE PYROPHOSPHATE (NFPP) ELECTRODE SHEETRESEARCH GRADE MATERIAL
|
||||||||||||||||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||||||||||||||
|
|||
|
TAILORED SOLUTIONS FOR RESEARCH
Contact our engineering team for technical support or official institutional quotations.
EMAIL: inquiry@atomfair.com
|
|||
|
Manufacturer: ATOMFAIR LLC
Brand: ATOMFAIR®
Disclaimer: Sold exclusively for laboratory research.
|
How is the electrode sheet baking time determined?
It is 12 hours under vacuum baking at 100°C.
How does the 94.5% active material ratio and 1.51 g/cm³ compaction density influence the achievable specific capacity and electrode porosity trade-off for sodium-ion battery testing?
The high active material ratio of 94.5% maximizes energy density, while the compaction density of 1.51 g/cm³ indicates a moderate packing degree. This combination yields a nominal capacity of 95 mAh/g, providing a balance between ionic transport and volumetric energy. Researchers should expect consistent electrochemical performance under standard testing conditions.
What precautions are necessary when integrating this single-side coated NFPP electrode into coin cells with sodium metal counter electrodes?
The single-side coating on carbon-coated aluminum foil requires careful alignment to avoid short circuits, as the uncoated side is conductive. The 12 μm thick foil with ±0.5 μm tolerance demands uniform pressure during cell assembly to prevent electrode deformation and ensure consistent contact.
The NFPP-S03 electrode sheet delivers a high active material ratio of 94.50% and a precise wet-process coating at 13 mg/cm² on carbon-coated aluminum foil, making it well-suited for sodium-ion battery R&D and reliable electrochemical analysis. Customization of coating and substrate dimensions is available to support varied laboratory requirements.
Positive
- High active material loading at 94.50%: The 94.50% active material ratio maximizes electrochemically active content per mass, enabling more accurate capacity and rate performance measurements in sodium-ion cell evaluations.
- Customizable coating and substrate parameters: Coating thickness/width and aluminum foil thickness/width can be tailored on request, allowing the electrode format to be adapted to specific test fixtures or experimental designs.
Trade-offs
- Requires 12-hour vacuum baking before use: The electrode sheets must be vacuum-baked at 100°C for 12 hours prior to cell assembly, adding a mandatory preconditioning step that extends preparation time and requires vacuum oven infrastructure.
- Single-sided coating limits cell configuration: As a single-side coated electrode, it is primarily suited for half-cell setups or full cells where a separate counter electrode is used; researchers planning symmetric or double-side configurations must account for this design constraint.
