A rectangular ATOMFAIR® NFPP-S06 sodium iron phosphate pyrophosphate cathode sheet with silver metal borders.
NFPP Single-Sided Electrode Sheet 22 mg/cm² ATOMFAIR® - Image 2
NFPP Single-Sided Electrode Sheet 22 mg/cm² ATOMFAIR® - Image 3
NFPP Single-Sided Electrode Sheet 22 mg/cm² ATOMFAIR® - Image 4
NFPP Single-Sided Electrode Sheet 22 mg/cm² ATOMFAIR® - Image 5

NFPP Single-Sided Electrode Sheet 22 mg/cm² ATOMFAIR®

$89.00

Institutional Procurement & Supply Compliance: As a verified US supplier, Atomfair accepts formal institutional Purchase Orders (POs), contract billing schedules, and custom procurement loops for university and national laboratories, and corporate R&D departments globally.

Research grade NFPP single-side electrode sheet with 22 mg/cm² coating density, 94.5% active material, on 12μm carbon-coated Al foil. 5 pack. Order now.

Quantity Price
1 – 4 $89.00
5+ $79.00
SKU: AFMSWNVA470
Category:
Tags: , , , ,
Brands:

Description

ATOMFAIR® NFPP-S06 SODIUM IRON PHOSPHATE PYROPHOSPHATE (NFPP) ELECTRODE SHEET

RESEARCH GRADE MATERIAL

Product Overview
Atomfair NFPP-S06 Sodium Iron Phosphate Pyrophosphate (NFPP) Electrode Sheet is single-side coated with 22 mg/cm² via a precise wet process. Ideal for sodium-ion battery R&D, this specialized cathode architecture delivers exceptional reliability for electrochemical performance analysis, ensuring cell-to-cell consistency, baseline testing control, variable elimination, and electrolyte validation platform benefits while nesting target sodium iron phosphate pyrophosphate electrode sheet price structures to optimize laboratory validation integrity.

Technical Specifications

PARAMETER DETAILS
1. Core Device & Electrochemical Design
Product Code S06
Capacity 95 mAh/g
Coating Process Wet Process
2. Cathode Parameters
Coating Material NFPP (Sodium Iron Phosphate Pyrophosphate)
Active Material Ratio 94.50%
Coating Density 22 mg/cm2
Coating Area 152 × 110 mm
Coating Type Single-sided
Compaction Density 1.58 g/cm3
3. Substrate & Foil Parameters
Substrate Material Carbon-coated aluminum foil matrix crystals
Current Collector Density 3.63 mg/cm2
Substrate Thickness 12 + 0.5 + 0.5 μm
Substrate Size 186 × 110 mm
4. Compliance & Support
Pack Size 5 sheets/pack
Manufacturing Rules Processed under strict ISO 9001 compliance conditions
Alternative Options Explore our related catalog or custom dimensions. For urgent technical custom requests or bulk inquiries, please contact our support team.

Key Features & Advantages
  • Homogeneous Material Purity: Features an optimized active material ratio of 94.50% to deliver a robust, highly uniform NFPP distribution across half-cell foils testing matrices.
  • Enhanced Operational Efficiency: Built on advanced carbon-coated aluminum foil substrates to maximize electrical contact, optimize boundary interfacial dynamics, and promote material evaluation accuracy.
  • Precision Wet Coating: Precise wet process single-sided coating coordinates an exceptionally uniform 22 mg/cm² loading profile across the 152 × 110 mm active area, securing reliable high-fidelity data outputs.
  • Tailored Solutions: Full customization options available for coating thickness, localized width, and current collector structural profiles to meet exact experimental specifications.

APPLICATION SCOPE: Sodium-ion battery Research and Development (R&D), laboratory testing, material evaluation, and reliable electrochemical performance analysis.
PACKAGING: 5 electrode sheets per pack (Substrate size: 186 × 110 mm), packaged meticulously to ensure consistent quality during laboratory baseline evaluations.
IMPORTANT NOTICE: This product is sold exclusively for laboratory research. Recommended baking protocol: Maintain strictly for 12 hours under vacuum at 100°C to prevent ambient phase contamination or structural degradation before thermal validation.

TAILORED SOLUTIONS FOR RESEARCH
Contact our engineering team for technical support or official institutional quotations.
EMAIL: inquiry@atomfair.com
Manufacturer: ATOMFAIR LLC
Brand: ATOMFAIR®
Disclaimer: Sold exclusively for laboratory research.

Store NFPP electrode sheets in a dry, inert atmosphere to prevent moisture-induced degradation. Handle sheets with clean tools to avoid contamination and mechanical damage to the coating.

  • Storage Atmosphere: Maintain storage in an argon-filled glovebox or vacuum desiccator to minimize exposure to ambient moisture and oxygen.
  • Handling Precautions: Use antistatic tweezers or gloves when handling to avoid electrostatic discharge and surface contamination.

Prepare the electrode sheet for sodium-ion battery testing by cutting, drying, and assembling into a coin cell. Follow standard glovebox procedures to maintain electrode integrity.

Required Equipment: Argon-filled glovebox, Precision cutter or scissors, Vacuum oven, Coin cell crimping tool

  1. Cut electrode
    Cut the NFPP-S06 sheet to the desired dimensions using a precision cutter to fit the coin cell components.
  2. Dry electrode
    Dry the cut electrode in a vacuum oven at elevated temperature to remove any adsorbed moisture before assembly.
  3. Assemble cell
    Assemble the coin cell in an argon glovebox using the dried electrode, a compatible separator, and sodium-ion electrolyte.
  4. Crimp and test
    Crimp the coin cell using a hydraulic crimping machine to ensure proper sealing and electrical contact.

How is the electrode sheet baking time determined?

It is 12 hours under vacuum baking at 100°C.

How does the compaction density of 1.58 g/cm³ impact the electrochemical performance of the NFPP-S06 electrode?

The specified compaction density of 1.58 g/cm³ provides a balance between electrode porosity and electronic conductivity, enabling the rated 95 mAh/g capacity at 22 mg/cm² loading. This density is optimized for sodium-ion half-cell and full-cell testing within the research-grade formulation.

What cutting or handling precautions are necessary for the 12 μm carbon-coated aluminum substrate of the NFPP-S06?

The 12 μm thick substrate, combined with the single-sided coating, requires careful cutting to avoid edge curling or active material delamination. Use a sharp blade or laser cutter, and store sheets flat between clean papers to preserve electrode integrity.

This NFPP electrode sheet offers a high 94.5% active material ratio and precise wet-process coating for sodium-ion battery R&D, but its single-side configuration and mandatory vacuum baking at 100°C for 12 hours introduce processing constraints.

Positive

  • High active material loading: 94.5% active material ratio maximizes energy density per unit mass, enhancing electrochemical performance in sodium-ion coin cells.
  • Precision wet-process coating: Wet-process deposition at 22 mg/cm² ensures uniform electrode thickness and density, yielding reproducible test results for R&D.

Trade-offs

  • Single-side coating limitation: Coating on only one side reduces areal capacity relative to double-side electrodes, requiring stacked configurations for higher-capacity cells.
  • Mandatory vacuum bake step: Sheets require vacuum baking at 100°C for 12 hours prior to use, adding processing time and necessitating compatible oven equipment.
