ATOMFAIR® Swagelok three-electrode testing cell with a vertical metallic plunger shaft grey connector cap and golden top pin tip.

Swagelok Three-Electrode Cell TC4/304 Stainless Research Grade

Price range: $109.95 through $119.95

Institutional Procurement & Supply Compliance: As a verified US supplier, Atomfair accepts formal institutional Purchase Orders (POs), contract billing schedules, and custom procurement loops for university and national laboratories, and corporate R&D departments globally.

Type 304 stainless steel three-electrode testing cell with TC4 grade alloy. Ideal for lithium-ion battery electrochemical measurements. Order now.

SKU: AFMSVVOW878
Category:
Brands:

Description

ATOMFAIR® SWAGELOK THREE-ELECTRODE TESTING CELL (TC4/304 STAINLESS STEEL)

RESEARCH GRADE MATERIAL

Product Overview
The ATOMFAIR® premium Swagelok three-electrode **testing cell** is precision-crafted from elite **TC4/304 stainless steel** to deliver superior mechanical durability and high corrosion resistance across battery research and development applications. As a fundamental tool for advanced **electrochemical testing equipment**, this cell features a precise **three-electrode configuration** that allows analytical researchers to effectively isolate and measure half-cell performance parameters across distinct electrode materials and electrolytes. Integrated with reliable, leak-proof **Swagelok fittings**, it guarantees tight, secure connections that minimize atmospheric ingress during long-term energy storage evaluation matrices, ensuring highly accurate data acquisition.

Technical Specifications
PARAMETER DETAILS
Equipment Type Electrochemical Testing Cell / Equipment
Electrode Configuration Three-Electrode Architecture (Working, Counter, Reference)
Structural Metallurgy High-Quality TC4 Titanium Alloy / 304 Stainless Steel
Connection Interfaces Reliable, Secure Swagelok Fittings
Design Form Factor Compact, Modular Layout for Rapid Benchtop Assembly
Battery Technology Adaptability Universal compatibility with Lithium-Ion, Solid-State, and Advanced Chemistries
Alternative Options Explore our related catalog or custom dimensions. For urgent technical custom requests or bulk inquiries, please contact our support team.

Key Features & Advantages
  • Advanced Three-Electrode Isolation: Optimized engineering allows for the isolation of individual half-cell reactions, ensuring exceptionally accurate dataset collection without voltage drop distortions.
  • Premium TC4 and 304 Metallurgy: High-grade stainless steel paired with titanium components ensures elite durability and corrosion defense against active chemical electrolyte solvents.
  • Leak-Proof Connection Security: Features standard Swagelok fitting architectures to achieve airtight seals, keeping the internal environment moisture-free during critical experiments.
  • Streamlined Spatial Footprint: Designed with a compact, easy-to-assemble framework that simplifies glovebox handling and shortens turnaround time between baseline evaluations.

APPLICATION SCOPE: Perfectly optimized for positive/negative electrode material validation, fundamental electrolyte evaluation, high-rate transient cycling arrays, lithium-ion diagnostics, and advanced electrochemical study configurations within academic and industrial laboratories.
PACKAGING: Dispatched in standard protective, contamination-free foam layouts to guarantee the safety of internal surfaces and fittings. Pricing inquiries can be forwarded directly via support@atomfair.com.
IMPORTANT NOTICE: Wash and dry all structural metallic components using electronic-grade solvents immediately after use to mitigate surface passivation. Always store the cell in a cool, clean, and desiccated storage window when idle. Comply strictly with localized regulations when treating or disposing of hazardous materials or chemical-soaked matrix residues.
TAILORED SOLUTIONS FOR RESEARCH
Contact our engineering team for technical support or official quotations.
EMAIL: inquiry@atomfair.com
Manufacturer: Atomfair LLC
Brand: ATOMFAIR®

The cell must be stored in a cool, dry location to preserve material integrity and prevent corrosion. Disposal of the cell must follow local hazardous materials regulations.

  • Storage Requirements: Store the cell in a cool, dry location to prevent moisture ingress and maintain seal integrity.

What performance trade-off exists when using a 304 stainless steel Swagelok three-electrode cell for electrolytes containing halide ions compared to polymer-based cells?

The high-quality stainless steel construction ensures durability and corrosion resistance for many standard battery electrolytes, but halide-containing solutions can accelerate pitting corrosion and introduce metallic contaminants into the measurement. Unlike polymer cells, the stainless steel body offers superior mechanical robustness but may compromise electrochemical window stability under aggressive halide exposure.

What electrode geometry constraints must be considered when integrating this Swagelok three-electrode cell with common potentiostat cables?

The compact design and reliable Swagelok fittings support a wide range of electrode sizes and types, making integration straightforward with standard laboratory potentiostats. Users should confirm that electrode lead connectors match the Swagelok thread interface to ensure secure electrical contact and reproducible measurements.

What specific handling procedures are required to maintain seal integrity and avoid contamination when assembling this three-electrode cell in an inert-atmosphere glovebox?

Store the cell in a cool, dry location as recommended. During glovebox assembly, avoid overtightening the Swagelok fittings to prevent damaging the sealing surfaces, and use clean, non-sharp tools to preserve the stainless steel finish. Proper torque application and periodic O-ring inspection are essential to maintaining a leak-free seal and preventing atmospheric contamination of air-sensitive electrolytes.

The Swagelok Three-Electrode Testing Cell in TC4/304 stainless steel offers a robust platform for battery research, combining corrosion-resistant construction with reliable Swagelok electrical connections to support accurate measurements across diverse electrode and electrolyte systems.

Positive

  • Durable stainless steel construction: High-quality TC4/304 stainless steel provides corrosion resistance and mechanical robustness suitable for repeated use in electrochemical testing environments.
  • Reliable Swagelok electrical connections: Swagelok fittings ensure secure, low-resistance electrical contacts that maintain signal integrity during three-electrode measurements.

Trade-offs

  • Requires cool, dry storage: The cell must be stored in a cool, dry location to prevent corrosion of the stainless steel components and maintain sealing integrity over time.
  • Hazardous material disposal needed: After use, the cell may contain residues from electrolytes or electrode materials; disposal must follow local regulations for hazardous materials.

Every advanced material, component, equipment, and instrument in our catalog is backed by rigorous testing. We maintain strict internal quality management frameworks and align with CE conformity metrics to deliver transparent, reproducible performance data via our public open-science repository.

To request raw batch performance data, submit formal vendor registration paperwork, or execute a fast-turnaround R&D manufacturing loop, contact us at inquiry@atomfair.com.

Item is dispatched under the Atomfair Shipping & Delivery Framework (Free worldwide shipping on orders over $59 USD). Return is governed by the Atomfair Return & Refund Policy (7-day technical return window).

Additional information

sizes

10mm, 12mm, 14mm, 16mm, 20mm
