Oil single-walled carbon nanotubeconductivepaste High concentration MWCNTs water dispersion(~14 wt%) High concentration carboxyl MWCNTs waterdispersion, 2.16-2.64 wt% content, OD 1.4±0.5 nm; Lengthum>100Product Type: Single-walled carbon nanotube material
Research-grade laboratory product
|
|||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||
|
LABORATORY PROCUREMENT SUPPORT
For model selection, material specification matching, application fit or quotation confirmation, contact our technical sales team.
E-MAIL: inquiry@atomfair.com
|
|||||||||||||||||||||||||||||||||
|
Supplier: Atomfair
Brand: ATOMFAIR®
|
Manufacturer: Atomfair LLC
Brand: ATOMFAIR®
This product is a single-walled carbon nanotube paste dispersed in NMP with PVDF binder. Its processing requires control of solid content and viscosity for consistent coating or dispersion performance.
- Solvent Compatibility: The NMP solvent system must be compatible with the intended substrate and processing equipment to avoid contamination or dissolution.
- Concentration Control: The solid content of 2.16-2.64 wt% and carbon nanotube content of 0.40 wt% must be precisely maintained to achieve target electrical conductivity.
- Viscosity Management: The paste viscosity below 5000 mPa·s is suitable for coating but may require adjustment if the solvent evaporates during storage.
What is the trade-off between the low nanotube content (0.40 wt%) and the high solid content (2.16-2.64 wt%) in this oil single-walled carbon nanotube conductive paste for electrode coating applications?
The low nanotube content (0.40 wt% of total paste) is balanced by the inclusion of PVDF binder (2+/-0.1 wt%) and NMP solvent (97.6 wt%). The solid content of 2.16-2.64 wt% ensures sufficient binder for film formation, but the nanotube loading is low, which may limit electrical conductivity per unit mass. This trade-off is optimized for dispersion stability and coating uniformity rather than maximum conductivity.
Is this oil-based single-walled carbon nanotube paste compatible with aqueous electrode slurries, or does it require an NMP-based formulation?
This paste is NMP-based (97.6 wt% NMP) and contains PVDF binder, making it directly compatible with NMP-based electrode formulations commonly used in lithium-ion battery cathodes. It is not designed for aqueous systems; the product's name includes a comparison to water dispersions, but the oil paste itself is intended for organic solvent processes. Users should confirm solvent compatibility before mixing with water-based slurries.
What are the recommended storage and handling conditions for this NMP-based single-walled carbon nanotube paste to prevent solvent evaporation and maintain viscosity?
The paste has a viscosity of ≤5000 mPa·s and contains 97.6 wt% NMP, a volatile solvent. Store in a tightly sealed container at room temperature (20-25°C) away from heat and open flames. Prolonged exposure to air will cause NMP evaporation, increasing viscosity and altering the solid content (2.16-2.64 wt%). Use within a reasonable timeframe after opening and re-disperse if necessary.
This oil-based single-walled carbon nanotube conductive paste (model AF-CNTP-OILSW-P200) is formulated with 2.16–2.64 wt% solid content, 0.40 wt% SWCNTs, and 2±0.1 wt% PVDF binder in NMP (97.6±0.1 wt%), providing a pre-dispersed, high-viscosity slurry for direct use in electrode coating or conductive composite preparation without additional dispersion steps.
Positive
- Pre-dispersed SWCNT paste with PVDF binder: The paste contains 0.40 wt% single-walled carbon nanotubes and 2±0.1 wt% PVDF in NMP, enabling direct use in slurry formulation for battery electrodes or conductive coatings without separate binder addition or dispersion optimization.
- Controlled metal impurity profile: Magnetized metal content is specified at low ppb levels (Cr 1.22, Cu 0.331, Fe 6.3, Mn 0, Ni 0, Zn 0 ppb), reducing contamination risk in electrochemical or electronic applications where trace metals affect performance.
Trade-offs
- NMP solvent requires handling precautions: The paste uses NMP (97.6±0.1 wt%) as the solvent, which requires proper ventilation, personal protective equipment, and waste disposal protocols due to its toxicity and regulatory classification as a reprotoxic solvent.
- Viscosity limits processing methods: With viscosity ≤5000 mPa·s and a black paste form, the material may require dilution or specialized coating equipment (e.g., slot-die or doctor blade) and is not suitable for low-viscosity spray or inkjet deposition without reformulation.
