ATOMFAIR® SILICON/CARBON (SI/C) ANODE ELECTRODERESEARCH GRADE MATERIAL
|
|||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||
|
TAILORED SOLUTIONS FOR RESEARCH
Contact our engineering team for technical support, custom requirements, or bulk orders.
EMAIL: INQUIRY@ATOMFAIR.COM
|
|||||||||||||||||||||||||||||||||||||||
|
Manufacturer: Atomfair LLC
Brand: ATOMFAIR®
|
|||||||||||||||||||||||||||||||||||||||
This electrode is moisture-sensitive and packaged in an aluminum laminated bag with desiccant. During electrochemical cycling, the silicon-carbon composite exhibits a volume expansion of less than 30%, requiring careful cell design to accommodate dimensional changes.
- Moisture Sensitivity: Store and handle the electrode under dry conditions to prevent degradation from ambient humidity.
- Volume Expansion: The electrode undergoes less than 30% volume expansion during cycling, which must be considered in cell stack pressure and separator selection.
- Current Collector Handling: The 6μm copper foil current collector is thin and susceptible to tearing; handle with care using tweezers or vacuum pickup tools.
- Packaging Integrity: Maintain the aluminum laminated bag seal until use to preserve the desiccant's effectiveness.
How does the 1.0 g/cc fixed compaction density of this Si/C anode affect its rate capability compared to lower-density designs?
The fixed 1.0 g/cc compaction density is optimized to balance porosity and ionic/electronic conductivity, supporting the 1350 mAh/g specific capacity and <30% volume expansion. This density favors volumetric energy density over ultra-high-rate performance; lower-density electrodes typically offer better ionic transport for high-C-rate applications.
Can this Si/C anode be integrated into standard lithium-ion battery assembly processes without modifications?
Yes, the electrode is supplied in a dry uncalendered format and is compatible with standard electrolytes as indicated in the product notice. However, the ultra-thin 6 μm copper foil current collector requires careful handling during cell assembly to prevent tearing, and custom pre-lithiation options are available for SEI stability studies.
What storage and handling conditions are required to preserve the performance of these Si/C anode sheets?
The electrodes are packaged in an aluminum laminated bag with desiccant; inert gas packaging is available for enhanced stability. They must be stored in a dry, inert atmosphere to prevent moisture uptake and oxidation of the silicon-carbon composite. The dry uncalendered format also demands gentle handling to avoid mechanical damage such as cracking or delamination.
This Si/C anode electrode offers a high specific capacity of 1350 mAh/g with low expansion (<30%), but is supplied in a dry uncalendered format with fixed compaction density (1.0 g/cc) and areal density (11 mg/cm² double side), necessitating additional processing and limiting experimental flexibility for electrolyte or binder optimization.
Positive
- High specific capacity: Delivers 1350 mAh/g, significantly exceeding conventional graphite anodes, enabling higher energy density in lithium-ion battery research.
- Low expansion design: Silicon-carbon composite structure limits volume change to <30% during cycling, enhancing structural integrity and prolonged cycle life.
Trade-offs
- Dry uncalendered format: Supplied without calendering, requiring an additional processing step to achieve target porosity and electrode density for consistent electrochemical performance.
- Fixed compaction and areal density: Compaction density at 1.0 g/cc and double-side areal density of 11 mg/cm² are not adjustable, limiting tailoring for specific electrolyte or binder systems in experimental setups.
