Description
Dedicated 48V High-Power AGV Lithium Battery System | 6kW+ Instantaneous Output
120A Hardware-Level Safety | IPX7 Waterproof | 3000 Cycle Industrial Grade Power
Product Overview
Engineered specifically for high-performance Automated Guided Vehicles (AGVs) and industrial automation, this system supports a massive instantaneous high-power output of 6kW+. It is designed to handle heavy-load startups and steep ramp climbing in demanding factory environments. Featuring a redundant safety architecture with 120A hardware-level forced power-off and a smart BMS capable of forced activation for deep-sleep cells, this system ensures surging power and ultimate operational safety for robotic fleets.
Technical Specifications
| Parameter | 48V45Ah Model | 48V52Ah Model |
|---|---|---|
| Cell Type / Configuration | Pouch Cell / 16S1P | |
| Typical Energy (Wh) | 2160Wh | 2496Wh |
| Continuous Charging Current | 0.5C | |
| Peak Discharge Current | 3.0C | |
| Dimensions (L*W*H) | 483 * 170 * 208 mm | |
| Communication Method | Bluetooth, RS485, CAN | |
| Operating Temp. (Charge) | 0 ~ 60°C | |
| Operating Temp. (Discharge) | -20 ~ 60°C | |
| IP Rating | IPX7 | |
| Cycle Life | 3000@70% | |
Core Features & Advantages
Extreme Power Output
Supports 6kW+ peak power, allowing industrial AGVs to easily navigate heavy loads and steep inclines without performance degradation.
Hardware-Level Safety Disconnect
Equipped with a 120A hardware-level forced power-off capability that actively cuts the circuit in extreme scenarios to ensure ultimate safety.
Intelligent Maintenance (O&M)
Supports BMS remote reset and forced charging activation for cells in deep sleep mode, significantly reducing downtime and service labor.
Application Scope
- Automated Guided Vehicles (Heavy-duty AGVs)
- AMR (Autonomous Mobile Robots)
- Industrial Automation Production Lines
- Intelligent Logistics & Warehousing Equipment
Accessories & Customization
BMS Integration: Real-time data streaming via Bluetooth APP, CAN, or RS485 for full fleet visibility.
Standard Footprint: 483mm length is compatible with standard industrial rack mounts and AGV chassis designs.
Advanced Safety: Full UN38.3, MSDS, and comprehensive industrial high-power discharge test reports available.
TAILORED SOLUTIONS FOR INDUSTRIAL ROBOTICS
Contact our engineering team for technical support, integration protocols, or official quotations.
