aqueous single-walled carbon nanotube conductive paste, 1.0±0.1 wt% content, OD 1.4±0.5 nm; Lengthum>100; Dispersant Content 0.6±0.03 wt%, model AF-CNTP-AQSW-P3000

aqueous single-walled carbon nanotube conductive paste, 1.0±0.1 wt% content, OD 1.4±0.5 nm; Lengthum>100; Dispersant Content 0.6±0.03 wt%

Product Type: Single-walled carbon nanotube material

Research-grade laboratory product

Product Overview

aqueous single-walled carbon nanotube conductive paste, 1.0±0.1 wt% content, OD 1.4±0.5 nm; Lengthum>100; Dispersant Content 0.6±0.03 wt% is a single-walled carbon nanotube material supplied with 1.0±0.1 wt% content, OD 1.4±0.5 nm; Lengthum>100; Dispersant Content 0.6±0.03 wt%. It is prepared for buyer comparison by model, material form, concentration or dimensional specification before quotation.

The specification table gives the measurable selection details available for this item, including material form, dimensional range, purity, content, conductivity, solvent or composition when supplied for the selected model.

Use this page to compare nanocarbon specifications before requesting a quotation, especially where functional group, concentration, geometry, package form or availability affects laboratory procurement.

Performance Features

Material form: aqueous single-walled carbon nanotube conductive paste identifies the single-walled carbon nanotube material for procurement comparison.
Appearance: Blackpaste; Content of single-walled carbon supports model matching against the required experiment or formulation workflow.
nanotubes: 0.40 wt.% supports model matching against the required experiment or formulation workflow.
Outside Diameter: 1.4±0.5 nm; Lengthum>100; Dispersant Content 0.6±0.03 wt% supports model matching against the required experiment or formulation workflow.
Solid Content: 1.0±0.1 wt% supports model matching against the required experiment or formulation workflow.
pH: 5.0~9.0 supports model matching against the required experiment or formulation workflow.

Technical Specifications

Parameter	Specification / Available Values
Atomfair Model	AF-CNTP-AQSW-P3000
Appearance	Blackpaste; Content of single-walled carbon
nanotubes	0.40 wt.%
Outside Diameter	1.4±0.5 nm; Lengthum>100; Dispersant Content 0.6±0.03 wt%
Solid Content	1.0±0.1 wt%
pH	5.0~9.0
Dispersant Content	0.6±0.03 wt%; Viscositym Pa•s<=5000; (Cr/Cu/Fe/Mn/Ni/Z
n)Magnetizedmetal	(1.22/0.331/3; 6.3/0/0/0)ppb

Selection and Use Notes

Match the material form and dimensional or concentration specification to the intended dispersion, composite, film, electrode, conductivity or nanocarbon research workflow.
Confirm the selected model, quantity, package size and application requirements before quotation.

QUOTATION DETAILS: Confirm nanotube type, concentration, solvent system, dispersion form and package size before quotation.

SPECIFICATION CONFIRMATION: Carbon nanotube content, solvent, viscosity or solid-content details are reviewed for the selected dispersion or slurry.

MATERIAL SELECTION: Aqueous, NMP, oil-based, paste and slurry forms can be matched to coating, conductive additive or composite preparation workflows.

QUOTATION REQUEST: Include nanotube type, solvent, concentration, package size and target use when requesting quotation support.

LABORATORY PROCUREMENT SUPPORT

For model selection, material specification matching, application fit or quotation confirmation, contact our technical sales team.

E-MAIL: inquiry@atomfair.com

Supplier: Atomfair

Brand: ATOMFAIR®

Manufacturer: Atomfair LLC

Brand: ATOMFAIR®

The product exhibits a pH range of 5.0–9.0, which constrains its compatibility with strongly acidic or alkaline components. Its viscosity is specified as ≤5000 mPa·s, affecting its suitability for spray, spin, or blade coating processes.

pH Compatibility Constraint: The pH range of 5.0–9.0 limits the paste's stability when mixed with materials outside this window.
Viscosity Processing Constraint: The maximum viscosity of 5000 mPa·s dictates the allowable shear rates and coating method parameters.

FAQ

How do the metal impurity levels in this aqueous SWCNT paste affect its suitability for electronic-grade applications?

The paste contains magnetized metal impurities at ppb levels: Cr 1.22, Cu 0.331, Fe 3, Mn 6.3, Ni 0, Zn 0, as specified in the technical specifications. While these are trace amounts, they may be problematic for ultra-high-purity electronic or semiconductor applications where ppb-level contaminants can degrade device performance. The product is classified as research-grade, so users should evaluate impurity tolerance against their specific process requirements.

What is the pH range of this aqueous SWCNT paste and is it compatible with typical battery electrode slurry formulations?

The paste has a pH of 5.0–9.0, making it compatible with neutral to slightly acidic or alkaline formulations commonly used in aqueous battery electrode processing. The aqueous base also aligns with water-based slurry preparation for lithium-ion electrodes, though the solid content of 1.0±0.1 wt% is lower than typical slurry solids and may require concentration adjustment or additional thickening agents.

How does the viscosity of this SWCNT paste influence its handling and coating processes?

The paste has a viscosity of ≤5000 mPa·s, indicating a thick, paste-like consistency suitable for screen printing or doctor blade coating. For spray coating or other low-viscosity processes, dilution or heating may be required. The dispersant content of 0.6±0.03 wt% helps maintain this viscosity while stabilizing the SWCNT dispersion, as noted in the product specifications.

Assessment

This aqueous single-walled carbon nanotube conductive paste (1.0±0.1 wt% solid content, OD 1.4±0.5 nm, length >100 μm) provides a high-aspect-ratio nanocarbon dispersion with controlled dispersant content (0.6±0.03 wt%) and low magnetized metal impurities, suitable for conductive coating or composite formulation workflows requiring consistent electrical percolation.

Positive

High aspect ratio SWCNT dispersion: Outside diameter of 1.4±0.5 nm and length >100 μm provide a high aspect ratio that facilitates electrical percolation at low loading fractions in composite or coating formulations.
Low magnetized metal impurity profile: Trace metal content (Cr 1.22 ppb, Cu 0.331 ppb, Fe 3.6 ppb, Mn 0 ppb, Ni 0 ppb, Zn 0 ppb) minimizes catalytic interference and contamination in sensitive electrochemical or electronic applications.

Trade-offs

Viscosity handling constraint: Viscosity ≤5000 mPa·s indicates a paste-like consistency that may require mechanical mixing or dilution prior to spray coating, inkjet printing, or spin-coating processes.
pH sensitivity for formulation compatibility: The pH range of 5.0–9.0 limits direct blending with strongly acidic or alkaline binder systems without pH adjustment or buffer incorporation to avoid aggregation or dispersant destabilization.
