High-purity Whisker carbon nanotubes, OD 20-200 nm(Mostofthem; were concentrated at 50; -100 nm), length 1-15 um, purity >95%Product Type: Carbon nanomaterial
Research-grade laboratory product
|
|||||||||||||||||||||||
|
|||||||||||||||||||||||
|
LABORATORY PROCUREMENT SUPPORT
For model selection, material specification matching, application fit or quotation confirmation, contact our technical sales team.
E-MAIL: inquiry@atomfair.com
|
|||||||||||||||||||||||
|
Supplier: Atomfair
Brand: ATOMFAIR®
|
Manufacturer: Atomfair LLC
Brand: ATOMFAIR®
How does the outer diameter distribution (20–200 nm, concentrated at 50–100 nm) influence the selection of these whisker carbon nanotubes for high-conductivity composite applications?
The outer diameter range of 20–200 nm, with the majority concentrated at 50–100 nm, provides a balance between high aspect ratio and dispersion uniformity. The concentrated fraction enables consistent percolation network formation in conductive composites, while the broader range can be leveraged for tailored mechanical reinforcement. This specification must be matched to the intended conductivity or composite workflow, as stated in the product selection notes.
What parameters must be specified when requesting a quotation for these whisker carbon nanotubes to ensure they meet the requirements of a specific electrode formulation?
When requesting a quotation, you must confirm nanotube wall type, outer diameter, length, purity, functional group, and package size. For this product, the outer diameter is 20–200 nm (concentrated 50–100 nm), inner diameter 2–5 nm, length 1–15 µm, and purity >95%. These details ensure the material matches the electrode or dispersion workflow, as emphasized in the procurement support notes.
How do I determine whether the pristine grade of these whisker carbon nanotubes is suitable for my specific application, or if a functionalized grade is required?
This product is supplied as high-purity whisker carbon nanotubes without specified functionalization, consistent with a pristine grade. For applications requiring specific surface chemistry, functionalized grades such as hydroxylated, carboxylated, or amino-modified can be matched to dispersion, electrode, or composite workflows, as listed in the material selection notes. The choice depends on the targeted interaction with the matrix or solvent in your experiment.
This high-purity whisker carbon nanotube product (AF-NM-C-MWCN-M077-R03V) offers a broad outer diameter distribution of 20–200 nm, with the majority concentrated at 50–100 nm, and a length of 1–15 μm at >95% purity, providing a versatile carbon nanomaterial for dispersion, composite, electrode, or conductivity research workflows.
Positive
- High purity and broad diameter range: Purity >95% with outer diameters spanning 20–200 nm (concentrated at 50–100 nm) supports flexible integration into dispersion, composite, and electrode formulations requiring varied nanotube dimensions.
- Multiple functionalization options available: Pristine, hydroxylated, carboxylated, amino-modified, graphitized, doped, and coated grades can be matched to specific dispersion, conductivity, or composite workflows, enabling tailored material selection.
Trade-offs
- Broad dimensional distribution requires matching: The outer diameter range of 20–200 nm and length range of 1–15 μm may introduce batch variability; careful specification matching is needed for experiments requiring narrow dimensional tolerances.
- Quotation required before procurement: Nanotube wall type, functionalization, diameter/length range, package size, and quantity must be confirmed via quotation, adding a pre-purchase coordination step for laboratory procurement.
