Fast Charge 14500 Cylindrical LTO Battery | ATOMFAIR

Fast Charge 14500 Cylindrical LTO Battery | ATOMFAIR

$6.00

Institutional Procurement & Supply Compliance: As a verified US supplier, Atomfair accepts formal institutional Purchase Orders (POs), contract billing schedules, and custom procurement loops for university and national laboratories, and corporate R&D departments globally.

0.55Ah 1.7V LTO 14500 cylindrical cell with 8C continuous charge/discharge, 20C pulse (10s), and up to 5000 cycles at 1C/1C. Wide temperature range: charge 0°C to +55°C, discharge -40°C to +55°C. Ideal for fast-charge applications.

Category:
Tags:
Brands:

Description

Fast Charge 14500 Cylindrical LTO Battery | 0.55Ah 1.7V 8C Rate – ATOMFAIR

COMMERCIAL GRADE · PRODUCTION

Product Overview
Designed for high-frequency power deployment and high-throughput reliability, this industrial cylindrical LTO battery utilizes an advanced lithium titanate chemical structure to achieve rapid recharging profiles. Optimized to function as an elite fast charge 14500 battery option, the 0.55Ah 1.7V lithium titanate matrix supports an intensive 8C high rate energy storage continuous charging and discharging envelope. This highly stable configuration yields outstanding cycle life metrics—sustaining up to ≥5000 loops under deep discharge usage without the dendrite growth risks typical of conventional setups. Its durable hard-shell cylinder structure and wide operating temperature threshold ensure uniform electron transfer down to sub-zero environments, making it an excellent cell standard for heavy start-stop devices, aerospace robotics prototyping, defense communication setups, and rugged data logging nodes. For bulk inquiries or official volume quotations, please contact us via email at inquiry@atomfair.com.

Technical Specifications

PARAMETER VALUE
1. Core Device & Electrochemical Design
Cell Format Standard Cylindrical Form Factor (14500 Profile)
Cell Chemistry Link LTO (Lithium Titanate Anode Interface)
Rated Capacity / Rated Voltage 0.55 Ah / 1.7 V (@ 0.2C Evaluation Rate)
Voltage Range Parameters 2.10 V Cut-off – 1.40 V Cut-off
AC Internal Resistance ≤ 100.0 mΩ (@ 50% State of Charge)
2. Cathode & Charge Parameters
Standard Charge Current 1.0 C
Max. Continuous Charge 8.0 C (Thermal cut-off @ 60°C)
Charge Temperature Range 0°C ~ +55°C
3. Anode & Discharge Parameters
Standard Discharge Current 1.0 C
Max. Continuous Discharge 8.0 C (Thermal cut-off @ 80°C)
Pulse Discharge Current (10s) 20.0 C (≥ 30% State of Charge)
Discharge Temperature Range -40°C ~ +55°C
4. Physical Package & Energy Metrics
Estimated Dimensions 14 mm × 50 mm (Φ × H)
Estimated Weight 19 g
Gravimetric Energy Density ≥ 50 Wh/kg (@ 0.2C Rate)
Volumetric Energy Density ≥ 120 Wh/L (@ 0.2C Rate)
Verified Lifecycle Metrics (@ 25°C) ≥ 5000 cycles (1C/1C 100% DOD) | ≥ 3000 cycles (8C/1C 100% DOD) | ≥ 2000 cycles (8C/8C 100% DOD)
Alternative Catalog Items Explore our complete component catalog for alternative volumetric capacities, high-conductivity polymer separators, aluminum-laminated protective packaging films, or multi-channel battery cycling systems.

Key Features & Advantages
  • Ultra-Fast Charging: Supports 8.0C maximum continuous charge, enabling full recharge in minutes. Standard 1.0C charging for daily use.
  • High Rate Discharge: 8.0C continuous discharge and 20.0C pulse discharge (10s) for peak power demands.
  • Exceptional Cycle Life: Up to ≥5000 cycles at 1C/1C, ≥3000 cycles at 8C/1C, and ≥2000 cycles at 8C/8C 100% DOD.
  • Wide Temperature Operation: Discharge from -40°C to +55°C and charge from 0°C to +55°C, reliable in cold environments.
  • Robust LTO Chemistry: Lithium Titanate anode provides intrinsic safety, excellent rate capability, and long calendar life.

APPLICATION SCOPE: Highly optimized for fast-recharge portable devices, power tools, grid-scale backup systems, cold-climate monitoring setups, and high-rate electronic testing applications.
SHIPPING & LOGISTICS: Secured within shock-damping hazardous material transport packaging boxes to preserve terminal connections. Arrives pre-calibrated and complete with comprehensive factory batch inspection data certificates.
IMPORTANT NOTICE: This fast charge 14500 LTO cell is designed for high-rate applications. Charge with CCCV profile, cut-off at 60°C during charging. Discharge cut-off at 80°C. Do not exceed specified current ratings. Store in dry, ventilated area between 15-30°C. Do not disassemble, short circuit, or expose to fire.

FAST CHARGE SOLUTIONS & CUSTOM ORDERS
Request a quote for samples, pilot runs, or mass production. Our engineering team supports high-rate LTO integration.
EMAIL: INQUIRY@ATOMFAIR.COM
Global logistics · Fast sample delivery · Technical datasheets available
Manufacturer: PETA ENERGY · MADE IN CHINA · INOVATION PLANTS · POLARIS ENERGY
Brand: ATOMFAIR
Specifications are representative and subject to change without notice. For the latest version and compliance certificates, contact official sales channel.

Every advanced material, component, equipment, and instrument in our catalog is backed by rigorous testing. We maintain strict internal quality management frameworks and align with CE conformity metrics to deliver transparent, reproducible performance data via our public open-science repository.

To request raw batch performance data, submit formal vendor registration paperwork, or execute a fast-turnaround R&D manufacturing loop, contact us at inquiry@atomfair.com.

Item is dispatched under the Atomfair Shipping & Delivery Framework (Free worldwide shipping on orders over $59 USD). Return is governed by the Atomfair Return & Refund Policy (7-day technical return window).
