ATOMFAIR® CO2 reduction system gas diffusion lab cell suite showing a multi-layered acrylic blocks assembly with steel tie rods and integrated metal gas inlet ports.

ATOMFAIR® CO2 REDUCTION SYSTEM GAS DIFFUSION LAB CELL SUITE

$2,000.00
Notice: Price for reference only. Please contact us directly for an updated quote.

Institutional Procurement & Supply Compliance: As a verified US supplier, Atomfair accepts formal institutional Purchase Orders (POs), contract billing schedules, and custom procurement loops for university and national laboratories, and corporate R&D departments globally.

Buy gas diffusion electrode cell price deals for electrocatalytic carbon dioxide reduction system R&D. ISO standard quality calibration. Contact inquiry@atomfair.com.

Category:
Tags:
Brands:

Description

ATOMFAIR® CARBON DIOXIDE REDUCTION COMPLETE SOLUTION SUITE

RESEARCH GRADE MATERIAL & EQUIPMENT

Product Overview
This premium suite delivers an optimized electrocatalytic testing matrix for carbon dioxide reduction reaction (CO2RR) validation workflows. Engineered to provide exceptional cell-to-cell consistency, lower thermal and fluidic transport resistance, and ideal baseline testing control, this unbundled hardware system eliminates testing variables across gas diffusion platforms. Featuring modular gas-diffusion cells, high-performance electrode components, and specialized ion exchange membranes, the entire catalog is structured to appeal to high-end laboratory validation and SCI-grade academic indexing.

Technical Specifications Catalog

CORE SYSTEM MODULE / COMPONENTS TECHNICAL SPECIFICATIONS / REMARKS
1. Gas Diffusion Electrolysis Cells (Select One Configuration)
Entry-Level Gas Diffusion Electrolytic Cell Standard configuration for fundamental gas diffusion testing.
Primary Gas Diffusion Electrolytic Cell (PMMA Material) Single chamber dimensions: 10×10×10mm or 20×20×10mm optional.
Primary Gas Diffusion Electrolytic Cell (PTFE Material)
Primary Gas Diffusion Electrolytic Cell (PEEK Material)
Gas Diffusion Electrolytic Cell Designed without observation window.
Observable Gas Diffusion Electrolytic Cell (Wide Gap) Includes analytical observation window; anode-to-cathode distance < 7mm.
Observable Gas Diffusion Electrolytic Cell (Narrow Gap) Includes analytical observation window; anode-to-cathode distance < 3mm.
Membrane Electrode-Gas Diffusion Multi-functional Cell Advanced dual-function matrix configuration; anode-to-cathode distance: 1.2mm.
Membrane Electrode Integrated Gas Diffusion Cell Zero-gap optimization matrix; anode-to-cathode distance: 0.4mm.
2. Auxiliary Fluidic Systems & Reference Electrodes
Water Management System Maintains precise hydration levels and variable elimination during running.
Ag/AgCl Reference Electrode (PEEK Shaft) SCI-grade potential tracking baseline. High chemical stability.
Hg/HgO Reference Electrode (PEEK Shaft) Optimized for alkaline electrochemical environments.
Platinum Foil Electrode Dimensions: 15×35×0.2mm high-purity catalytic substrate.
Peristaltic Pump Module Controlled mass transport delivery profile.
3. Ion Exchange Membranes & Consumable Matrix
Anion Exchange Membrane Fuma-FAA-3-50 selective transport architecture.
Cation Exchange Membrane N117 configuration; dimensions: 100×100mm.
Hydrophobic Carbon Paper Dimensions: 100×100mm; Packed 10 pieces per box.
Titanium Mesh Oxide Substrate Dimensions: 100×100mm; Titanium baseline with loading weight: 0.2mg/cm².
Salt Bridge Connection Eliminates liquid junction potential artifacts.
Conductive Copper Tape Dimensions: 5mm width × 50 meters length.
4. Flow Control & Measurement Hardware
Liquid Flow Cell Channel Uniform electrolyte velocity validation platform.
PTFE Tubing Substrate Dimensions: 3mm inner diameter × 5 meters length. High chemical immunity.
Steady-Flow Accumulator Vessel Volume: 30ml; dampens fluidic pulsation to secure phase consistency.
Gas-Liquid Mixing Pump Features integrated high-shear cutting force processing.
Mass Flow Meter High-precision gas dosing validation system.
Manufacturing Standards Processed and calibrated under strict ISO 9001 and international electrochemical hardware testing conditions. All dimensions listed represent standard catalog inventory. Custom configurations, chamber volumes, and specific material sizing are available upon official request. Please contact our engineering team to request formal institutional quotes and pricing details.

Key System Advantages
  • Homogeneous Flow Dynamics: Engineered to provide uniform electrolyte velocity and gas distribution profiles across the active matrix layer.
  • Optimized Mass Transport Kinetics: Zero-gap and ultra-narrow gap selections dramatically lower solution resistance and promote gas boundary integration.
  • Rigid Corrosion Immunity: Crafted from premium high-density PMMA, PTFE, and PEEK substrates to protect research workflows against parasitic background contamination.

APPLICATION SCOPE: Lab-scale Electrocatalytic CO2 Reduction, Flow Cell Mechanism Studies, Gas Diffusion Electrode (GDE) Evaluation, and General Secondary Energy Device R&D.
IMPORTANT NOTICE: Components must be rinsed thoroughly with deionized water post-testing to eliminate salt precipitation and scale degradation across channels before next validation.
TAILORED SOLUTIONS FOR CO2RR RESEARCH
Contact our engineering team for specialized architecture requests or official institutional quotations.
EMAIL: inquiry@atomfair.com
Manufacturer: Atomfair LLC  |  Brand: ATOMFAIR®

Every advanced material, component, equipment, and instrument in our catalog is backed by rigorous testing. We maintain strict internal quality management frameworks and align with CE conformity metrics to deliver transparent, reproducible performance data via our public open-science repository.

To request raw batch performance data, submit formal vendor registration paperwork, or execute a fast-turnaround R&D manufacturing loop, contact us at inquiry@atomfair.com.

Item is dispatched under the Atomfair Shipping & Delivery Framework (Free worldwide shipping on orders over $59 USD). Return is governed by the Atomfair Return & Refund Policy (7-day technical return window).
