ATOMFAIR Double Sided Graphite Anode Sheet 7.2mg
Graphite Double Side Anode 7.2 mg/cm² Wet Process 5 Pack - Image 2
Graphite Double Side Anode 7.2 mg/cm² Wet Process 5 Pack - Image 3
Graphite Double Side Anode 7.2 mg/cm² Wet Process 5 Pack - Image 4

Graphite Double Side Anode 7.2 mg/cm² Wet Process 5 Pack

$89.00

Institutional Procurement & Supply Compliance: As a verified US supplier, Atomfair accepts formal institutional Purchase Orders (POs), contract billing schedules, and custom procurement loops for university and national laboratories, and corporate R&D departments globally.

Atomfair  S01-Graphite Electrode Sheet, 7.2 mg/cm²,Single-sided wet coating with standard density.

Quantity Price
1 – 4 $89.00
5+ $79.00
SKU: AFMSVITT255
Category:
Tags: , , , ,
Brands:

Description

Atomfair S01-Graphite (Gr) Electrode Sheet

RESEARCH GRADE MATERIAL

Product Overview

Atomfair S01-Graphite (Gr) Electrode Sheet is single-side coated with 7.2 mg/cm² via a precise wet process. It is ideal for Lithium-ion battery R&D, providing high reliability for electrochemical performance analysis. Each pack includes 5 sheets, ensuring consistent quality for laboratory testing and material evaluation.

Customization Options: This Graphite Carbon-coated copper foil can be fully customized upon request. Parameters such as coating thickness/width, and copper foil thickness/width can be tailored to meet your exact specifications. Please feel free to contact us to specify your requirements.

Electrode Sheet Design Parameters
PARAMETER VALUE
Product code S01
Coating material Gr
Active material ratio 96.50%
Coating density 7.2 mg/cm²
Coating area 152*100 mm
Coating Type Single-sided
Substrate material Carbon-coated copper foil
Current collector areal density 5.45 mg/cm²
Substrate thickness 12 +0.5 +0.5 μm
Substrate size 186*100 mm
Compaction Density –
Capacity 350 mah/g
Coating Process Wet Process
Pack Size 5 sheets/pack

Frequently Asked Questions (FAQ)
Q: How is the electrode sheet baking time determined?
A: It is 12 hours under vacuum baking at 100°C.

APPLICATION SCOPE: Lithium-ion battery Research and Development (R&D), laboratory testing, material evaluation, and reliable electrochemical performance analysis.
PACKAGING: 5 sheets per pack.
DISCLAIMER / NOTICE: Sold exclusively for laboratory research.
TAILORED SOLUTIONS FOR RESEARCH
If you’re interested, have any questions, or have specific customization requirements, please feel free to contact us.
Manufacturer: Atomfair LLC
Brand: ATOMFAIR®

Quality Standards & Performance Verification

Every advanced material, component, equipment, and instrument in our catalog is backed by rigorous testing. We maintain strict internal quality management frameworks and align with CE conformity metrics to deliver transparent, reproducible performance data via our public open-science repository.

To request raw batch performance data, submit formal vendor registration paperwork, or execute a fast-turnaround R&D manufacturing loop, contact us at inquiry@atomfair.com.

Shipping & Returns

Item is dispatched under the Atomfair Shipping & Delivery Framework (Free worldwide shipping on orders over $59 USD). Return is governed by the Atomfair Return & Refund Policy (7-day technical return window for completely unopened items).
