High nickel 46800 NCM cylindrical battery cell containing an advanced tabless current collector and a layered oxide cathode structure.

46800 High-Nickel NCM Cylindrical Battery Series | ATOMFAIR

Price range: $79.00 through $83.00

Institutional Procurement & Supply Compliance: As a verified US supplier, Atomfair accepts formal institutional Purchase Orders (POs), contract billing schedules, and custom procurement loops for university and national laboratories, and corporate R&D departments globally.

High energy density 46800 NCM cylindrical battery series with 3.6V nominal voltage. Available in 27.8Ah high-capacity and 24.6Ah high-rate configurations.

Category:
Tags:
Brands:

Description

46800 High-Nickel NCM Cylindrical Battery Series

COMMERCIAL GRADE · PRODUCTION

Product Overview
The ATOMFAIR® 46800 High-Nickel NCM (LiNixCoyMn1-x-yO2) cylindrical cell series delivers industry-leading energy density in the large-format 46mm×80mm platform. Featuring a Ni-rich cathode (Ni≥85%) and advanced tabless architecture, this series is available in high-rate (AF46800NCM01, 5C discharge) and high-energy (AF46800NCM02, 27.8Ah) configurations. These cells provide exceptional power density and cycle life for next-generation electric vehicles, eVTOL, and high-performance stationary storage.

Technical Specifications

PARAMETER VALUE
Model AF46800NCM01 AF46800NCM02
Weight 446 ± 10 g 470 ± 10 g
Nominal Voltage 3.6 V 3.6 V
Nominal Capacity (0.33C) 24.6 Ah 27.8 Ah
Charge/Discharge Rate 3C / 5C 1C / 2C
Cycle Life @70% Capacity >1500 cycles >2000 cycles
Manufacturing Compliance: Fully traceable production under ISO 9001:2025 and IATF 16949 standards. Custom form factors or electrode formulations available upon request.

Key Features & Advantages
  • Ultra-High Energy Density: Ni-rich NCM cathode (Ni≥85%) delivers up to 27.8Ah per cell, enabling extended range in EV and eVTOL platforms.
  • Dual Performance Tiers: AF46800NCM01 (5C discharge) for high-power PHEV/HEV; AF46800NCM02 (27.8Ah) for long-range BEV.
  • Advanced Tabless Design: 46800 form factor with proprietary tabless current collector reduces internal resistance (≤4 mΩ) and improves thermal uniformity.
  • Robust Cycle Stability: Advanced electrolyte additives minimize transition metal dissolution, achieving 1500-2000 cycles to 70% SOH.
  • High Voltage Platform: 3.6V nominal voltage enables higher system voltage with fewer series connections.

APPLICATION SCOPE: Battery electric vehicles (BEV), plug-in hybrids (PHEV), eVTOL aircraft, high-performance stationary storage, and automotive-grade R&D.
PACKAGING: Vacuum-sealed moisture-barrier cartons with cell dividers (2 cells per tray, 50 cells per master carton). Terminal covers included.
IMPORTANT NOTICE: High-nickel NCM cells are sensitive to moisture and overcharge. Always store in <10% RH environment. Maximum charge voltage: 4.2V ±0.05V. Use only with battery management system (BMS) providing cell balancing and overvoltage protection.

Frequently Asked Technical Questions

What is the gravimetric energy density of AF46800NCM02?

AF46800NCM02 delivers approximately 213 Wh/kg (27.8Ah × 3.6V = 100 Wh, divided by 0.470 kg). This represents industry-leading performance for 46800 cells.

Can I charge AF46800NCM01 at 3C continuously?

Continuous 3C charging is allowed with active cooling (cell surface temperature <45°C). For maximum cycle life, we recommend 1C charging. The 3C rating applies to pulse charging (≤30 seconds) or with aggressive thermal management.

How does 46800 NCM compare to 21700 in pack-level energy density?

The 46800 format reduces inactive materials (busbars, cooling plates) by ~20% compared to 21700, improving pack-level energy density by 15-20% for the same chemistry.

What safety certifications does this series hold?

The AF46800NCM series complies with UN38.3 (transport), UL 1642 (cell safety), and IEC 62133-2:2021. Automotive-grade PPAP documentation is available for OEM customers.

What is the recommended storage voltage and temperature?

For long-term storage (>3 months), store at 30% SOC (≈3.7V) in a dry environment at 15-25°C. Refresh charge every 6 months. Avoid storage at full charge (4.2V).
TAILORED SOLUTIONS FOR RESEARCH
Contact our engineering team for technical support or official institutional quotations.
EMAIL: inquiry@atomfair.com
Manufacturer: Atomfair LLC
Brand: ATOMFAIR®

Quality Standards & Performance Verification

Every advanced material, component, equipment, and instrument in our catalog is backed by rigorous testing. We maintain strict internal quality management frameworks and align with CE conformity metrics to deliver transparent, reproducible performance data via our public open-science repository.

To request raw batch performance data, submit formal vendor registration paperwork, or execute a fast-turnaround R&D manufacturing loop, contact us at inquiry@atomfair.com.

Shipping & Returns

Item is dispatched under the Atomfair Shipping & Delivery Framework (Free worldwide shipping on orders over $59 USD). Return is governed by the Atomfair Return & Refund Policy (7-day technical return window for completely unopened items).

Additional information

Nominal Capacity

24.6 Ah, 27.8 Ah
