ATOMFAIR T-Shaped Tungsten Working Electrode with 2mm to 4mm embedded tip and PTFE insulative body.

T-Shaped Tungsten Working Electrode series | ATOMFAIR

$69.00

Institutional Procurement & Supply Compliance: As a verified US supplier, Atomfair accepts formal institutional Purchase Orders (POs), contract billing schedules, and custom procurement loops for university and national laboratories, and corporate R&D departments globally.

T-Shaped Tungsten Working Electrode series | ATOMFAIR RESEARCH GRADE INSTRUMENT Product Overview The ATOMFAIR® T-Shaped Tungsten Working Electrode features an embedded tungsten tip with diameter options ranging from 2mm to 4mm. The electrode is equipped with a gold-plated copper rod (1.5x15mm) for enhanced corrosion resistance and stable conductivity. The rod body is manufactured from premium polytetrafluoroethylene (PTFE), offering excellent chemical inertness and thermal stability. This electrode is designed to deliver consistent, research-grade performance across a wide spectrum of electrochemical applications, with tungsten as the primary material providing exceptionally high melting point, outstanding hardness, excellent electrical conductivity, superior corrosion resistance, and…

Category: ,
Tags: , ,
Brands:

Description

T-Shaped Tungsten Working Electrode series | ATOMFAIR

RESEARCH GRADE INSTRUMENT

Product Overview
The ATOMFAIR® T-Shaped Tungsten Working Electrode features an embedded tungsten tip with diameter options ranging from 2mm to 4mm. The electrode is equipped with a gold-plated copper rod (1.5x15mm) for enhanced corrosion resistance and stable conductivity. The rod body is manufactured from premium polytetrafluoroethylene (PTFE), offering excellent chemical inertness and thermal stability. This electrode is designed to deliver consistent, research-grade performance across a wide spectrum of electrochemical applications, with tungsten as the primary material providing exceptionally high melting point, outstanding hardness, excellent electrical conductivity, superior corrosion resistance, and remarkable performance in high-temperature electrochemical studies, electro-catalysis, and specialized sensor applications.

Technical Specifications

PARAMETER DETAILS
1. Core Device & Electrochemical Design
Electrode Geometry T-Type Cylindrical Configuration with flat embedded disk
Connector Rod Copper rod with gold-plated finish (1.5 x 15mm)
Insulative Body Polytetrafluoroethylene (PTFE)
2. Electrode Material Portfolio Parameters
Material Tungsten
Diameter Options 2~4mm


Key Features & Advantages

  • Specialized Tungsten Material: Constructed from high-grade tungsten, providing excellent high-temperature resistance and specific electrochemical characteristics suitable for corrosion research, electrocatalytic studies, and targeted redox systems.

  • Precision Embedded Design: T-Shaped cylindrical geometry with standardized tip diameters promotes reproducible electrode placement and uniform current density distribution across all sizes.

  • Robust Corrosion Protection: Gold-plated copper rod (1.5x15mm) delivers enhanced oxidation resistance and maintains stable conductivity over extended use.

  • Flexible Diameter Selection: Available in 2mm to 4mm diameter range, accommodating various experimental requirements and allowing researchers to select the optimal size for their specific application.
APPLICATION SCOPE: Healthcare, Environmental Monitoring, Chemical Engineering, Bio-industry, and Advanced Energy Systems.
PACKAGING: Secure individual research-grade protective containers with shock-absorption parameters.
IMPORTANT NOTICE: This product is highly sensitive to surface contamination. Keep containers tightly sealed or handle exclusively within an anhydrous inert environment to prevent phase contamination or degradation before electrochemical validation.
TAILORED SOLUTIONS FOR RESEARCH
Contact our engineering team for technical support or official institutional quotations.
EMAIL: inquiry@atomfair.com
Manufacturer: Atomfair LLC
Brand: ATOMFAIR®
