ATOMFAIR® EB100G-0.01G-01 LABORATORY PRECISION ELECTRONIC BALANCESCI-GRADE MEASUREMENT SYSTEM
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
The EB100G-0.01G-01 precision balance requires a vibration-isolated work surface to achieve rated linearity and repeatability. Overload safeguards protect the internal transducer, and electrical isolation circuits filter ambient disturbances to maintain calibration stability.
- Vibration Isolation Requirement: Place the balance on a structured, vibration-isolated work table to prevent structural vibrations from degrading measurement accuracy.
- Overload Protection Mechanism: The balance's physical stops and electronic limiters prevent damage when loads exceed the maximum capacity of 100g.
- Electrical and Structural Noise Filtering: Dual transducer protection loops isolate the sensor from power grid fluctuations and ambient structural signals to secure calibration linearity.
What is the effective measurement uncertainty of the EB100G-0.01G-01 balance at 100g capacity, and what infrastructure is needed to maintain its specified linearity?
The balance specifies repeatability of ±0.01g and linearity of ±0.02g at full capacity. Achieving the stated 0.01g linearity requires a structured, vibration-isolated work table per the compliance notice; otherwise, ambient structural vibrations can degrade accuracy. The dual transducer protection loops and power line filtering partially mitigate interference, but the table is mandatory for full linearity mapping.
Can the EB100G-0.01G-01 balance be integrated into an automated data logging system for piece-counting workflows?
Yes, the balance includes a standard RS232 communication port for direct digital data logging to laboratory desktop PCs. Its intelligent firmware supports piece-counting application functions, enabling real-time weight-to-count conversion for small parts. No additional adapters are required beyond a standard RS232 cable.
What overload and power-source protections are built into the EB100G-0.01G-01 balance for field or mobile use?
The balance features a double overload safeguard architecture combining physical mechanical stops and electronic limiters to protect the internal transducer from shock. It also supports flexible AC/DC hybrid power routing, allowing seamless operation outside standard bench electricity grids via an external DC source. Both features are integrated into the hardened firmware with automatic baseline auto-zeroing and fault tracking alarms.
The ATOMFAIR EB100G-0.01G-01 is a 100g capacity precision balance with 0.01g readability, featuring dual transducer protection and AC/DC power routing for stable operation. It requires a vibration-isolated work surface to maintain specified linearity and repeatability.
Positive
- Dual transducer & hybrid power: Advanced dual transducer protection loops and flexible AC/DC power routing isolate ambient structural signals and grid fluctuations, safeguarding calibration linearity and reproducibility.
- Double overload safeguard: Integrated mechanical stops and electronic limiters protect the internal transducer from unexpected shock, enhancing durability in busy lab environments.
Trade-offs
- Requires vibration-isolated table: To maintain full 0.01g linearity mapping, the balance must be placed on a structured, vibration-isolated work table, adding an infrastructure requirement.
- Small pan size limits containers: The Φ130mm pan diameter restricts the size of sample containers that can be used, which may be a constraint for bulkier vessels.
