Single-sided silicon carbon Si/C anode electrode sheet 1350 mAh/g 5.5 mg/cm² S01 by Atomfair for high-capacity lithium batteries.
ATOMFAIR® Silicon Carbon (Si/C) Anode Electrode Sheet - 1350 mAh/g, Single-Sided, 5.5 mg/cm² S01, 5 Pack - Image 2
ATOMFAIR® Silicon Carbon (Si/C) Anode Electrode Sheet - 1350 mAh/g, Single-Sided, 5.5 mg/cm² S01, 5 Pack - Image 3
ATOMFAIR® Silicon Carbon (Si/C) Anode Electrode Sheet - 1350 mAh/g, Single-Sided, 5.5 mg/cm² S01, 5 Pack - Image 4

ATOMFAIR® Silicon Carbon (Si/C) Anode Electrode Sheet – 1350 mAh/g, Single-Sided, 5.5 mg/cm² S01, 5 Pack

$89.00

Atmofair S01-Silicon Carbon (1350mAh/g) Electrode Sheet, 5.5 mg/cm²,Single-sided wet coating with standard density.

Quantity Discount (%) Price
1 – 4 — $89.00
5+ — $99.00
Category:
Tags: , , , , ,
Brands:

Description

Atomfair Si/C-S01 Silicon Carbon (1350mAh/g) Electrode Sheet

RESEARCH GRADE MATERIAL

Product Overview
The Atomfair Si/C-S01 is a high-capacity Silicon Carbon electrode sheet, single-side coated with 5.5 mg/cm² via a precision wet process. Engineered for next-generation Lithium-ion battery R&D, this material delivers a high specific capacity of 1350 mAh/g. It is designed to provide consistent quality for rigorous laboratory testing, material evaluation, and advanced electrochemical performance analysis.

Technical Specifications
PARAMETER DETAILS
Product Code S01
Coating Material Si/C (Silicon Carbon)
Active Material Ratio 90.30%
Coating Density 5.5 mg/cm²
Coating Area 140 * 80 mm
Coating Type Single-sided
Substrate Material Carbon-coated copper foil
Current Collector Areal Density 5.4 mg/cm²
Substrate Thickness 12 + 0.5 + 0.5 μm
Substrate Size 160 * 100 mm
Capacity 1350 mAh/g
Coating Process Wet Process

Key Features & Advantages
  • Ultra-High Capacity: Si/C composite active material yielding 1350 mAh/g for high-energy density studies.
  • Enhanced Current Collection: Carbon-coated copper foil substrate improves interfacial contact and reduces internal resistance.
  • Customization Capability: Flexible adjustment of coating thickness, coating width, and foil specifications to meet specific research needs.
  • Ready for Lab Use: Standardized vacuum baking protocol (12 hours at 100°C) ensures material readiness and stability.

APPLICATION SCOPE: Lithium-ion battery R&D, electrochemical performance analysis, and material characterization.
PACKAGING: 5 sheets per pack, ensuring uniform quality across batches.
IMPORTANT NOTICE: Sold exclusively for laboratory research. Standard processing involves 12 hours under vacuum baking at 100°C.
TAILORED SOLUTIONS FOR RESEARCH
Contact our engineering team for technical support or specific customization requirements.
Manufacturer: Atomfair LLC
Brand: ATOMFAIR®
