ATOMFAIR® High-Solid Carbon Nanotube-Graphene Hybrid Slurry CXA372T

CXA372T is a high-solid-content (12.00%) conductive slurry combining carbon nanotubes (A30) and graphene (10.00% conductive agent). It offers a balanced viscosity (≤3000 cps) and fine particle size (D50 ≤1 μm). With low metal impurities (Fe ≤50 ppm, Co ≤50 ppm) and moisture (<1000 ppm), it is ideal for cost-effective, high-performance applications.

Description

High-Solid Carbon Nanotube-Graphene Hybrid Slurry CXA372T

Name: ATOMFAIR® High-Solid Carbon Nanotube-Graphene Hybrid Slurry CXA372T - SKU: - ATOMFAIR
Brand: Atomfair®

RESEARCH GRADE MATERIAL

Product Overview

CXA372T is a high-solid-content (12.00%) conductive slurry combining carbon nanotubes (A30) and graphene (10.00% conductive agent). It offers a balanced viscosity (≤3000 cps) and fine particle size (D50 ≤1 μm). With low metal impurities and moisture, it is ideal for cost-effective, high-performance applications.

Technical Specifications

PROPERTY	SPECIFICATION
Solid Content	12.00% ±0.2%
Conductive Agent	10.00% ±0.2%
Dispersant	2.00% ±0.2%
Moisture	<1000 ppm
Viscosity	≤3000 cps
Particle Size (D50)	≤1 μm
Fe (ppm)	≤50
Co (ppm)	≤50
Ni (ppm)	≤10
Cu (ppm)	≤10
Zn (ppm)	≤10
Cr (ppm)	≤10
Magnetic Impurities	<0.5 ppm

Key Features & Advantages

Synergistic Carbon Nanotube-Graphene Framework: Integrates a high-performance hybrid network utilizing Type A30 linear nanotubes and planar graphene sheets to maximize overlapping conductive zones.
High-Solid Process Fluidics: Delivers a concentrated 12.00% solid fraction alongside a balanced viscosity configuration (≤3000 cps) optimized for cost-effective manufacturing and formulation scaling.
Refined Sub-Micron Dispersion: Maintains highly uniform sub-micron architectural spacing (D50 ≤1 μm) to promote intense structural interconnectivity and matrix stability.
Strict Background Control: Monitors trace elements tightly (Fe, Co ≤50 ppm; Ni, Cu, Zn, Cr ≤10 ppm each) and guarantees low moisture levels for sensitive lab applications.

APPLICATION SCOPE: High-loading energy storage electrodes, electrochemical interfaces, thin-film advanced devices, and cost-effective high-performance industrial compounding studies.

PACKAGING: Sealed in professional laboratory-grade, airtight chemical containers to perfectly maintain low moisture profiles and eliminate airborne environmental cross-contamination.

DISCLAIMER / IMPORTANT NOTICE: Sold exclusively for laboratory research. This material is an advanced fluid nano-dispersion; proper mechanical agitation or sonication is recommended before characterization to ensure optimal volumetric uniformity.
