Atomfair S04 single-sided graphite anode electrode sheet with 27.4 mg/cm² dry process coating for high-performance battery research.
ATOMFAIR® Graphite Anode Electrode Sheet (Single-Sided), Dry Process, 27.4 mg/cm², 5 Pack - Image 2
ATOMFAIR® Graphite Anode Electrode Sheet (Single-Sided), Dry Process, 27.4 mg/cm², 5 Pack - Image 3
ATOMFAIR® Graphite Anode Electrode Sheet (Single-Sided), Dry Process, 27.4 mg/cm², 5 Pack - Image 4

ATOMFAIR® Graphite Anode Electrode Sheet (Single-Sided), Dry Process, 27.4 mg/cm², 5 Pack

$89.00

Atmofair S04-Graphite Electrode Sheet, 27.4 mg/cm²,Single-sided dry coating with high areal density.

Quantity Discount (%) Price
1 – 4 — $89.00
5+ — $99.00
Category:
Tags: , , , , ,
Brands:

Description

Atomfair S04-Graphite (Gr) Electrode Sheet

RESEARCH GRADE MATERIAL

Product Overview

Atomfair S04-Graphite (Gr) Electrode Sheet is single-side coated with 27.4 mg/cm² via a precise dry process. It is ideal for Lithium-ion battery R&D, providing high reliability for electrochemical performance analysis. Each pack includes 5 sheets, ensuring consistent quality for laboratory testing and material evaluation.

Customization Options: This Graphite Carbon-coated copper foil can be fully customized upon request. Parameters such as coating thickness/width, and copper foil thickness/width can be tailored to meet your exact specifications. Please feel free to contact us to specify your requirements.

Electrode Sheet Design Parameters
PARAMETER VALUE
Product code S04
Coating material Gr
Active material ratio 96.00%
Coating density 27.4 mg/cm²
Coating area 90*120 mm
Coating Type Single-sided
Substrate material Carbon-coated copper foil
Current collector areal density 7.3 mg/cm²
Substrate thickness 12 +0.5 +0.5 μm
Substrate size 90*140 mm
Compaction Density 1.31 g/cm³
Capacity 350 mah/g
Coating Process Dry Process
Pack Size 5 sheets/pack

Frequently Asked Questions (FAQ)
Q: How is the electrode sheet baking time determined?
A: It is 12 hours under vacuum baking at 100°C.

APPLICATION SCOPE: Lithium-ion battery Research and Development (R&D), laboratory testing, material evaluation, and reliable electrochemical performance analysis.
PACKAGING: 5 sheets per pack.
DISCLAIMER / NOTICE: Sold exclusively for laboratory research.
TAILORED SOLUTIONS FOR RESEARCH
If you’re interested, have any questions, or have specific customization requirements, please feel free to contact us.
EMAIL: inquiry@atomfair.com
Manufacturer: Atomfair LLC
Brand: ATOMFAIR®
