Dry process double-sided NCM811 cathode electrode sheet 61 mg/cm² D03 by Atomfair for lithium-ion battery.
ATOMFAIR® NCM811 Cathode Electrode Sheet for Li-ion Battery - D03, Dry Process, Double-Sided, 61 mg/cm², 5 Pack - Image 2
ATOMFAIR® NCM811 Cathode Electrode Sheet for Li-ion Battery - D03, Dry Process, Double-Sided, 61 mg/cm², 5 Pack - Image 3

ATOMFAIR® NCM811 Cathode Electrode Sheet for Li-ion Battery – D03, Dry Process, Double-Sided, 61 mg/cm², 5 Pack

$109.00

Atmofair NCM811-D03 lithium nickel cobalt manganese oxide Electrode Sheet,61 mg/cm², Double-sided dry coating with ultra-high density.

Quantity Discount (%) Price
1 – 4 — $109.00
5+ — $119.00
Category:
Tags: , , , , , ,
Brands:

Description

Atomfair NCM811-D03 lithium nickel cobalt manganese oxide (NCM811) Electrode Sheet

RESEARCH GRADE MATERIAL

Product Overview
Atomfair NCM811-D03 is a premium lithium nickel cobalt manganese oxide (NCM811) electrode sheet, double-side coated with 61 mg/cm² via an advanced dry process. Ideal for Lithium-ion battery R&D, this pack includes 5 sheets to ensure consistent quality for lab testing and material evaluation. It provides dependable parameter controls required for rigorous electrochemical performance analysis.

Technical Specifications
PARAMETER DETAILS
Product code D03
Coating material NCM811
Active material ratio 96.0%
Coating density 61 mg/cm²
Coating area 90*120 mm
Coating Type Double-sided
Substrate material Carbon-coated aluminum foil
Current collector areal density 4.4 mg/cm²
Substrate thickness 12 +0.5 +0.5 μm
Substrate size 90*140 mm
Compaction Density 3.3 g/cm³
Capacity 200 mah/g
Coating Process Dry Process

Key Features & Advantages
  • High Active Material Ratio: Premium 96.0% formulation to optimize electrochemical evaluation accuracy.
  • Advanced Dry Process Coating: Delivers superior structural integrity and highly uniform 61 mg/cm² density control.
  • Carbon-Coated Substrate: Minimizes interfacial contact resistance and maximizes functional cell stability.
  • Flexible Customization: Tailored adjustments for coating thickness/width and aluminum foil parameters available upon request.

APPLICATION SCOPE: Lithium-ion battery R&D, material evaluation, and systematic electrochemical performance analysis.
PACKAGING: 5 sheets/pack, ensuring strict batch uniformity for advanced lab testing.
IMPORTANT NOTICE: Sold exclusively for laboratory research. Standard drying protocol requires 12 hours under vacuum baking at 100°C.
TAILORED SOLUTIONS FOR RESEARCH
Contact our engineering team for technical support or official quotations.
EMAIL: inquiry@atomfair.com
Manufacturer: Atomfair LLC
Brand: ATOMFAIR®
Disclaimer: Sold exclusively for laboratory research.
