Double-sided silicon carbon Si/C anode electrode sheet 1350 mAh/g 11 mg/cm² D01 by Atomfair for high-energy density lithium-ion batteries.
ATOMFAIR® Silicon Carbon (Si/C) Anode Electrode Sheet - 1350 mAh/g, D01, Double-Sided, 11 mg/cm², 5 Pack - Image 2
ATOMFAIR® Silicon Carbon (Si/C) Anode Electrode Sheet - 1350 mAh/g, D01, Double-Sided, 11 mg/cm², 5 Pack - Image 3

ATOMFAIR® Silicon Carbon (Si/C) Anode Electrode Sheet – 1350 mAh/g, D01, Double-Sided, 11 mg/cm², 5 Pack

$89.00

Atmofair D01-Silicon Carbon (1350mAh/g) Electrode Sheet, 11 mg/cm²,Double-sided wet coating with compaction density.

Quantity Discount (%) Price
1 – 4 — $89.00
5+ — $99.00
Category:
Tags: , , , ,
Brands:

Description

Atomfair Si/C-D01 Silicon Carbon (1350mAh/g) Electrode Sheet

RESEARCH GRADE MATERIAL

Product Overview
The Atomfair Si/C-D01 is a premium Silicon Carbon electrode sheet designed for advanced Lithium-ion battery R&D. Featuring a double-sided coating with a density of 11 mg/cm² applied via a precision wet process, this material offers a high theoretical capacity of 1350 mAh/g. It provides the consistency and reliability essential for rigorous lab testing, material evaluation, and electrochemical performance analysis.

Technical Specifications
PARAMETER DETAILS
Product Code D01
Coating Material Si/C (Silicon Carbon)
Active Material Ratio 90.30%
Coating Density 11 mg/cm²
Coating Area 140 * 80 mm
Coating Type Double-sided
Substrate Material Carbon-coated copper foil
Current Collector Areal Density 5.4 mg/cm²
Substrate Thickness 12 + 0.5 + 0.5 μm
Substrate Size 160 * 100 mm
Compaction Density 1.0 g/cm³
Capacity 1350 mAh/g
Coating Process Wet Process

Key Features & Advantages
  • High Specific Capacity: 1350 mAh/g Si/C composite active material for high-energy density electrode research.
  • Advanced Substrate: Carbon-coated copper foil enhances interfacial adhesion and reduces contact resistance.
  • Double-Sided Precision: Uniformly coated on both sides using a wet process to ensure balanced electrochemical activity.
  • Fully Customizable: Flexible customization for coating thickness, width, and copper foil parameters upon request.

APPLICATION SCOPE: Lithium-ion battery R&D, material evaluation, and electrochemical performance analysis.
PACKAGING: 5 sheets per pack, vacuum-sealed to maintain consistent quality.
IMPORTANT NOTICE: Sold exclusively for laboratory research. Recommended baking condition: 12 hours under vacuum at 100°C.
TAILORED SOLUTIONS FOR RESEARCH
Contact our engineering team for technical support or official quotations.
EMAIL: inquiry@atomfair.com
Manufacturer: Atomfair LLC
Brand: ATOMFAIR®
