Dry process single-sided lithium-rich manganese-based LMR cathode sheet 35 mg/cm² S03 by Atomfair for high-energy density batteries.
ATOMFAIR® Lithium-rich Manganese-based (LMR) Cathode Sheet - S03, Single-Sided, 35 mg/cm², Dry Process, 5 Pack - Image 2
ATOMFAIR® Lithium-rich Manganese-based (LMR) Cathode Sheet - S03, Single-Sided, 35 mg/cm², Dry Process, 5 Pack - Image 3
ATOMFAIR® Lithium-rich Manganese-based (LMR) Cathode Sheet - S03, Single-Sided, 35 mg/cm², Dry Process, 5 Pack - Image 4

ATOMFAIR® Lithium-rich Manganese-based (LMR) Cathode Sheet – S03, Single-Sided, 35 mg/cm², Dry Process, 5 Pack

$109.00

Atmofair LMR-S03 Lithium-rich Manganese-based Cathode Electrode Sheet,35 mg/cm², Single-sided dry coating with optimized density.

Quantity Discount (%) Price
1 – 4 — $109.00
5+ — $119.00
Category:
Tags: , , , , , ,
Brands:

Description

Atomfair LMR-S03 Lithium-rich Manganese-based Cathode (LMR) Electrode Sheet

RESEARCH GRADE MATERIAL

Product Overview
Atomfair LMR-S03 is a premium Lithium-rich Manganese-based Cathode (LMR) electrode sheet, featuring a single-sided coating with 35 mg/cm² mass loading applied via an advanced dry process. Optimized specifically for Lithium-ion battery R&D, this material delivers excellent electrochemical uniformity. Each pack includes 5 sheets, ensuring consistent batch quality for high-precision laboratory testing, material characterization, and reliable electrochemical performance analysis.

Technical Specifications
PARAMETER DETAILS
Product code S03
Coating material LMR
Active material ratio 96.00%
Coating density 35 mg/cm²
Coating area 90*120 mm
Coating Type Single-sided
Substrate material Carbon-coated aluminum foil
Current collector areal density 4.2 mg/cm²
Substrate thickness 12 +0.5 +0.5 μm
Substrate size 90*140 mm
Compaction Density 2.5 g/cm³
Capacity 300 mah/g
Coating Process Dry Process

Key Features & Advantages
  • High Specific Capacity: Engineered for premium performance with a 300 mAh/g material design capacity and a 96.00% active ratio formulation.
  • Advanced Dry Processing: Ensures superior electrode film cohesion, robust structure, and stable 35 mg/cm² coating thickness control.
  • Carbon-Coated Substrate: Minimizes interfacial contact resistance and contact polarization to promote long-term cycling stability.
  • Flexible Customization: Tailored alterations for coating geometry (thickness/width) and aluminum substrate specifications are fully supported.

APPLICATION SCOPE: High-capacity Lithium-ion battery R&D, structural material validation, and advanced electrochemical diagnostics.
PACKAGING: 5 sheets per pack configuration to safeguard strict laboratory batch constants.
IMPORTANT NOTICE: Sold exclusively for laboratory research. Standard electrode conditioning protocol targets 12 hours under vacuum baking at 100°C.
TAILORED SOLUTIONS FOR RESEARCH
Contact our engineering team for technical support or custom fabrication inquiries.
Manufacturer: Atomfair LLC
Brand: ATOMFAIR®
Disclaimer: Sold exclusively for laboratory research.
