Description
Atomfair LMR-S05 Lithium-rich Manganese-based Cathode (LMR) Electrode Sheet: Single side coated with 30 mg/cm² via dry process. Ideal for Lithium-ion battery R&D. Pack includes 5 sheets, ensuring consistent quality for lab testing and material evaluation. Reliable for electrochemical performance analysis.
This LMR (Lithium-rich Manganese-based Cathode) coated aluminum foil can be customized upon request, such as coating thickness/width, and aluminum foil thickness/width. Please feel free to contact us to specify your exact requirements.
Electrode Sheet Design Parameters
| Parameter | Value |
| Product code | S05 |
| Coating material | LMR |
| Active material ratio | 96.00% |
| Coating density | 30 mg/cm² |
| Coating area | 120*90 mm |
| Coating Type | Single-sided |
| Substrate material | Carbon-coated aluminum foil |
| Current collector areal density | 4.4 mg/cm² |
| Substrate thickness | 12 +0.5 +0.5 μm |
| Substrate size | 140*90 mm |
| Compaction Density | – |
| Capacity | 300 mah/g |
| Coating Process | Dry Process |
| Pack Size | 5 sheets/pack |
FAQ
If you’re interested, have any questions, or have specific customization requirements, please feel free to contact us at inquiry@atomfair.com.
Disclaimer: Sold exclusively for laboratory research.
