Atmofair NFPP-S04 Sodium Iron Phosphate Pyrophosphate Electrode Sheet – Single Side Coating, 31 mg/cm², Dry Process, 5 Pack Sheets
A high-loading single-side electrode with 31 mg/cm² areal density manufactured using dry process. It features a high compaction density for enhanced performance.
Description
Atmofair NFPP-S04 Sodium Iron Phosphate Pyrophosphate Electrode Sheet: Single side coated with 31 mg/cm² via dry process. Ideal for sodium-ion battery R&D. Pack includes 5 sheets, ensuring consistent quality for lab testing and material evaluation. Reliable for electrochemical performance analysis.
This NFPP (Sodium Iron Phosphate Pyrophosphate) coated aluminum foil can be customized upon request, such as coating thickness/width, and aluminum foil thickness/width. Please feel free to contact us to specify your exact requirements.
Electrode Sheet Design Parameters
| Parameter | Value |
| Product code | S04 |
| Coating material | NFPP |
| Active material ratio | 94.50% |
| Coating density | 31mg/cm² |
| Coating area | 90*120 mm |
| Coating Type | Single-sided |
| Substrate material | Carbon-coated aluminum foil |
| Current collector areal density | 4.4mg/cm² |
| Substrate thickness | 12 +0.5 +0.5 μm |
| Substrate size | 90*140 mm |
| Compaction Density | 1.90g/cm³ |
| Capacity | 95 mah/g |
| Coating Process | Dry Process |
| Pack Size | 5 sheets/pack |
FAQ
If you’re interested, have any questions, or have specific customization requirements, please feel free to contact us at inquiry@atomfair.com.
Disclaimer: Sold exclusively for laboratory research.
