Description

Product Overview:
The Atomfair Silicon/Carbon (Si/C) Anode Electrode delivers a high specific capacity of 1350 mAh/g with a fixed compaction density of 1.0 g/cc, ultra-thin 6μm copper foil current collector, and optimized 5.5 mg/cm² areal density at 90.2% active material ratio. Each pack contains 5 pre-cut electrodes, ensuring consistency and convenience for experimental use. Engineered for minimal volume expansion and extended cycling performance, this electrode is ideal for high-energy-density lithium-ion battery research and development.

Key Features:

• High Specific Capacity: 1350 mAh/g (typical), significantly exceeding conventional graphite anodes.
• Low Expansion Design: Silicon-carbon composite structure limits volume change to <30% during cycling.
• Optimized Compaction: Fixed 1.0 g/cc density balances porosity and ionic/electronic conductivity.
• Controlled Areal Density: 5.5 mg/cm² (single-side coating) with 90.2% active material content for high reproducibility.
• Ultra-Thin Current Collector: 6μm copper foil reduces inactive weight and enhances energy density.
• Standardized Packaging: 5 sheets per pack, minimizing handling and contamination risks.
• Long Cycle Life: >80% capacity retention after 500 cycles (0.5C rate).

Specifications:

Parameter	Value
Active Material	Silicon-Carbon Composite (Si/C)
Specific Capacity	1350 mAh/g
Compaction Density	1.0 g/cc (fixed)
Areal Density	5.5 mg/cm² (single-side, default)
Active Material Ratio	90.2%
Current Collector	6μm copper foil
Expansion Rate	<30%
Packaging	5 sheets per pack (aluminum laminated bag with desiccant)

Applications:

• High-energy-density batteries for EVs, portable electronics, and aerospace
• Silicon anode integration and scalability studies
• Long-cycle performance and SEI stability testing

Note:
Dry uncalendered format. Compatible with standard electrolytes. Custom areal densities and pre-lithiation options available. Inert gas packaging optional for enhanced stability.
