Description



Atomfair Battery Short-Circuit Tester

Product Model

Atomfair-SCT-706

Release Date

2022-03-12

Version

V2.0

Dimensions & Weight

• Dimensions: 300 × 88 × 380 mm (W×H×D)
• Weight: 7.2 kg

Product Overview

Short-circuit tester specially designed for battery cells and capacitive loads. Output voltage 25V–1000V adjustable by 1V step. Judges by insulation resistance or leakage current. Supports 100 groups of parameter storage, RS232 and PLC interface for automatic control.

Key Features

• Output voltage 25V–1000V, 1V step, wide insulation resistance range
• Built-in discharge module (20kΩ) for safe operation
• Fast charge, ideal for cell testing
• 100 groups of parameter storage
• Upper/lower comparator with audible and visual alarm
• Delay judgment function for capacitive products
• Test terminals on front and rear panels
• Standard RS232 and PLC remote interface
• Continuous and manual testing supported

Technical Specifications

• Output voltage: 25V–1000V, resolution 1V
• Accuracy: ±(2%×setting +2V)
• Max current: 1mA
• Insulation resistance: 2.000MΩ–4000MΩ
• Delay time: 0.1s–999.9s
• Test time: 0.5s–999.9s
• Auto discharge: 20kΩ
• Interface: RS232 / PLC
• Power supply: AC 220V, 50Hz
• Weight: 7.2kg
• Dimensions: 300×88×380 mm (W×H×D)
